Double Slideway Drilling Machine Hc-1600h Heavy Duty Industrial Radial Drilling Machine

Product Description

High rigidity, heavy drilling, double slideway design, stable operation
√ Strong drilling ability, Mehanna tough cast iron, high temperature tempering, rigid and tough.
√ The gear is made of alloy steel, by quenching and carburizing heat treatment.
√ The spindle is made of chrome-molybdenum diamond, outstanding durability.

	Spindle Box Fixed range machining, spindle forward and reverse rotation, speed change, neutral and other actions are all controlled by a handle. ∨		Worktable The worktable has undergone aging treatment, making is sturdy and stable for a long time of use. ∨
∧ High Frequency Quenching Column The columns are all high-frequence quenched, with strong rigidity and high surface finish.		∧ Spindle The spindle is made of chrome-molybdnum diamond, outstanding durability.

Double Slideway Drilling Machine HC-1600H Heavy Duty Industrial Radial Drilling Machine

Model		HC-1600H
Distance between spindle center and column center	Max	1600
	Min	350
Distance between spindle nose to base	Max	1215
	Min	320
Diameter of spindle	E	350
Height of column	F	2600
Max distance between spindle head to base	G	2860
Floor space	HXI	2380*980
Longitudinal travel of spindle head	K	1250
Up and down travel of radial ram	L	580
Up and down travel of spindle	M	315
Spindle hole	MT	NO.5
Size of worktable	mm	1650*980
Motor of spindle	kw	3.75(5HP)*4P
Elevator motor of radial ram	kw	1.5(2HP)*4P
Motor for clamping	kw	0.375(1/2HP)*4P
Spindle feed range	mm/rev	0.04-3.2
	Grade	16
Spindle rotation	60HZ rpm	40-2550
	50HZ rpm	25-2000
	Grade	16
Working capacity	Drilling	55
	Tapping (S45C)	42
Net weight	kg	3500
Gross weight	kg	3800
Dimension	mm	2650*1280*2500

Shenzhen Joint Machinery Co., Ltd. stands as a beacon of excellence in the manufacturing and export of sophisticated CNC lathe machines, CNC deep hole drilling machines, and Swiss-type automatic lathes, among others. Our unwavering commitment to delivering machines of unparalleled quality is matched by our dedication to providing exceptional customer service on a global scale. Through rigorous quality control and continuous enhancement, our products are crafted to meet the most stringent industry standards. By leveraging cutting-edge Taiwanese and German core technologies, alongside advanced production equipment and methodologies, we deliver machines that excel in precision, stability, and reliability. Renowned for their superior performance, our products adeptly fulfill complex and rigorous machining demands across diverse industries. Our global footprint extends across Asia, Europe, South America, North America, and beyond, with our products earning widespread acclaim and popularity. We forge enduring partnerships worldwide, generating significant business value and fostering mutual growth.

---
