Keithley 2015 2015-P Multimeter with Voltage and Current Testing Capabilities

Product Description

The 2015-P Audio Analyzing Digital Multimeter and the 2015 Total Harmonic Distortion Multimeter combine audio band quality measurements and analysis with a full-function 6½-digit DMM. Test engineers can make a broad range of voltage, resistance, current, frequency, and distortion measurements, all with the same compact, half-rack measurement instrument. The 2015-P offers additional processing capacity for frequency spectrum analysis.
Key Features
• THD, THD+Noise, and SINAD measurements
• 20 Hz-20 kHz sine wave generator
• Fast frequency sweeps
• 2015-P identifies peak spectral components
• Sine wave generator maximum amplitude: 4 Vrms single-ended or 8 Vrms differential output • Individual harmonic magnitude measurements
• 5 standard audio shaping filters
• 13 DMM functions (6½ digits)
• GPIB and RS-232 interfaces
Frequency Domain Distortion Analysis
For applications such as assessing non-linear distortion in components, devices, and systems, DSP-based processing allows the 2015 and 2015-P to provide frequency domain analysis in conventional time domain instruments. They can measure Total Harmonic Distortion (THD) over the complete 20 Hz to 20 kHz audio band. They also measure over a wide input range (up to 750 Vrms) and have low residual distortion (-87 dB). The THD reading can be expressed either in decibels or as a percentage. In addition to THD, the 2015 and 2015-P can compute THD+Noise and Signal-to-Noise plus Distortion (SINAD). For analyses in which the individual harmonics are the criteria of greatest interest, the instruments can report any of the (up to 64) harmonic magnitudes that can be included in the distortion measurements. The user can program the actual number of harmonics to be included in a computation, so accuracy, speed, and complexity can be optimized for a specific application
Company Profile
Packaging & Shipping
FAQ
1,Who are we?
Dongguan Qihang Electronic Technology Co., Ltd. is a professional company engaged in the research and development, sales, maintenance, measurement, technical consulting, and provision of Bluetooth RF testing systems and testing solutions for RF, microwave, and electronic testing instruments.
2,How to ensure quality?
Before shipment, our quality inspector will conduct a comprehensive test of the product to ensure that the customer receives the instrument without any issues
3,What can I buy from here?
We can provide various instruments for Keysight, Ceyear, Tektronix, Rohde&Schwarz, Agilent, Keithley, Anritsu, and Lecroy
4,Why do you want to purchase from us instead of other suppliers?
We have good prices and the advantage of overseas warehouses, which can make the goods arrive faster. And a good after-sales solution.
5,Where do we ship from and how long is the delivery time?
Shipping from Guangdong, China, with a delivery time of 15 working days.

---
