WQ-320 Model Reel Type Automatic Silk Screen Printing Machine for Label Stickers

Product Description

WQ-320 Reel Type screen Printing Machine for Labels
This machine is used for printing on reel material such as PVC,OPP,Nylon,hologram label,
adhensive label sticker,etc. the material feeding of this machine is controlled by servomotor,
the main drive part adopted the pneumatic device,and the printing position is followed and
controlled by photocell. the machine has the characteristic of high accurate of color register,
steady material-feeding,automatic counter and alarm,convenient adjust and compact structure,etc.
Main specifications:

Model	WQ-320
Printing speed	10-50m/min
Max. web width	320mm
Max. printing width	300mm
Max. printing length	320mm
Max. unwinding diameter	450mm
Printing repeat length	175-355mm
Precision of color register	±0.15mm
Main motor power	1.2kw
Oven power	4.1kw
Air pressure needed	4.5-6kg/c
Main machine dimension	2.4x0.95x1.5m
Overall dimensions	1.75x0.6x1.8m
Weight	About 1100kg

---
