Mtu 3000kVA 3mva Container Type Diesel Generator

Product Description

1. GENERATOR DATA
Voltage Available:
50Hz: 380-400-415V/220-230-240V;
60Hz: 220-380-416-440-480V/110-208-220-240V
Any special voltage is also available as client's request
Prime Power:
Comply with GB/T2820-97(eqv.ISO8528).
Genset can run unlimitedly under certain power range.
One hour 10% over load in every 12 running hours is allowed;
Standby Power:
standby power is the limit value of maximum output for emergency use.
It is off-oil power,overloading is prohibited
2. MAIN SPECIFICATION

Genset Model		KPMT2270	KPMT2400	KPMT2750	KPMT3000	KPMT3250
Rated Power	KW/KVA	1650 /2063	1800 /2250	2000 /2500	2200 /2750	2400/3000
Standby Power	KW/KVA	1815 /2269	1980 /2400	2200 /2750	2400 /3000	2600/3250
Rated Voltage	V	220V/127V 380V/220V 400V/230V 415V/240V 480V/277V 600V/346V
Speed	RPM	1500/1800
Rated frequency	Hz	50/60
Engine Model		16V4000G23	16V4000G63	20V4000G23	20V4000G63	20V4000G63L
Engine Power	KW	1798	1965	2200	2420	2590
Air intake way		Turbo	Turbo	Turbo	Turbo	Turbo
Governor		Electronic	Electronic	Electronic	Electronic	Electronic
Cylinder	QTY	16	16	20	20	20
Bore*Stroke	mm*mm	170x210	170x210	170x210	170x210	170x210
Displacement	L	76.3	76.3	95.4	95.4	95.4
Fuel Consumption	g/kw.h	192	191	195	193	192
Compression Ratio		16.5:1	16.5:1	16.5:1	16.5:1	16.5:1
Alternator Model		STF-734F	STF-734G	AMG 0500BB04	AMG 0500CC04	AMG 0500DD04
Voltage Regulation		AVR
Excitation Method		Brushless
Open Type Size	mm	5800x2250x2600	5800x2250x2600	7000x2250x2600	7000x2250x2600	7000x2250x2600
Open Type Weight	kg	15600	16800	17300	18200	19000
Soundproof Size	mm	7800x2300x2650	7800x2300x2650	9800x2250x2650	9800x2250x2650	9800x2250x2650
Soundproof Weight	kg	19800	21500	23000	23900	24060

3. PRODUCT FEATURES
(1) Full control panel with power indicator light and oil light.
(2) Emergency shutdown for low oil pressure and high water temperature.
(3) Large fuel tank ensure continuous running.
(4) Low noise & vibration.
(5) Compact structure.
(6) Reliable performance.
(7) Easy for installation and maintenance.
(8) 50Hz and 60Hz both are available for choice

---
