LSR Baby Nipple Injection Molding Machine, Silicone Injection Molding Machine

Product Description

liquid silicone injection molding machine
Applications:
Liquid silicone injection machines are often used in medical care, labor insurance, electronic packaging, adult products, baby products and other industries:
1)Liquid silicone daily used products: gloves, cup mat, ice cube tray, menstrual cup and so on.
2) Liquid silicone baby products: baby nipple, baby pacifier, baby soother, baby toothbrush, baby silicone bottle, silicone toys, etc.s
3)Liquid silicone diving & swimming products: swimming supplies, diving supplies
4) Liquid silicone medical part: prosthetic, the capsule, laryngeal mask capsule, oxygen mask, protective mast, catheter, balloon, medical belt etc.
5)Sex toys/adult products, which vibrating spear, sex toy coat, adult supplies etc.s
6)Electronics and industrial product: watchband, mobile phone case, valve, O-ring, sealing part, auto parts and more.
7)Silicone high-voltage cable accessories
Features: Fasten lower mold, upper mold will be controlled by up/down switch. Enough space for insert parts and finishing goods releasing. High speed clamping molds by hydraulic oil, low speed increasing pressure, friendly adjust pressure and speed, no impact noise when open molds. Pilot-operated type adjusting pressure, stable and useful. Quick reaction & energy conservation. Two phases injection speed & pressure controlling, independent module conduct melting and injection to ensure quality. Import electronic components from Europe & Japan, computer control machine, digital speed & pressure & timing & cycle calculating will be appeared on LED. Production Descriptions
(Liquid Silicone Rubber) Vertical Injection Molding Machine
1.Multiple phases precision mold electric heating temperature control;
2.LSR machine has special hydraulic oil pressure and cooling water sealing nozzle;
3.Specialized barrel for LSR machine.
4.Hot & cool water switch board and insulate glass fiber board;
5.Taking/placing parts with disc or single/double plate design, use LSR machine to control thermosetting molding and dwell time, operator can take/put insert port product from another molds, or clean molds, greatly increase efficiency.
6.Special feeding & injection design, precise measurement in feeding.
7.Separately order adjustable vacuum device to prevent bubble.
8.Various hydraulic oil system (Semi-Closed Loop, Servo motor or high-speed injection) designs can meet customer requirements.
please send the message about your requirments below to customized your product,KIndly share your mold & plastic products drawings with me will be highly appreciated.let's get the effective communication.
1)raw material of your product
2)net weight of product as well as the runner weight
3)mold dimension if you have in hand
Specification

	Item		Unit	DHLS-850			DHLS-1200			DHLX-1500
Injection device	Screw Dia.		mm	¢26	¢28	¢30	¢30	¢35	¢40	¢40	¢45	¢50
	Ideal Injection volume		cm3	74	86	98	98	134	175	251	317	392
	Max. Injection pressure		Mpa	252	217	189	265	194	149	168	132	107
	Inject stroke		mm	140			140			200
	Screw rotating speed		r.p.m	0~240			0~240			0~240
	Nozzle protrusion plate size		mm	≥60			≥60			≥60
Clamping Device	Clamping force		KN	861			1125			1504
	Clamping stroke		mm	250			300			300
	Min. Mould thickness		mm	250			250			260
	Max. Daylight		mm	650			650			610
	Space between bars		mm	390*660			470*660			610*650
	Max. Mould size		mm	450*550			550*600			550*750
	Ejector stroke		mm	145			175			245
	Ejector force		KN	33.2			46.4			53.8
Others	System pressure		Mpa/cm2	14			14			14
	Oil tank capacity		L	365			450			433
	Heating power		KW	12			12			18
	Motor power		KW	11			11			18.5
	Size	L*W	mm	2200*2100			2700*2200			3900*1150
		H	mm	2800/3590			3300/4200			3200/4100
	Gross weight		T	5.5			6.5			8
