Water Pouch Packing Machine

Product Details

Product Description

Product Description
This water pouch packing machine is high precision packing machine and the most advanced liquid (sachet) packing machine in china, which is standing, three side sealing and intermittent.
The sachet machine is integrated with UltraViolet sterilization, Sachet forming, quantitative filling, sealing, printing, cutting and counting .Controlled by microprocessor and automatic photocell (Optional Function).
It is widely used to pack all kinds of liquid without gas, especially soy, wine, vinegar, juice, soybean milk, peanut oil, vegetable oil, plant oil, mineral water and liquid chemical products.
Technology Parameter of Water Pouch Packing Machine:

Model		DZS-1000
Production Capacity		1500-2000 sachets per hour
Filling range		100-1000ml
Voltage / Frequency		AC220V/50HZ
Film-transporting Motor		250W/220V
Size of the Sachet Length (mm)		30-120mm
Size of the Sachet Width (mm)		120-160mm
Power of Hot Sealing	Vertical	300W
	Horizontal	500W
Main motor power		370W/220V
Packing Dimension		1000*800*1800
G.N weight		450Kg /400kg
(1) Bag (sachet )-forming (2) UV sterilization (3) Thermal vertical sealing (4) Date lamination (5) Linear bag traction (6) quantitative filling (7) Thermal transverse sealing (8) Bag-cutting (9) Automatic counting (10) Photocell monitoring ( Available according to client’s demand)

---
