| US$800.00-950.00 | 18 Pieces (MOQ) |
| Model Number | A200 |
| Engine/Drive | |
| Engine | 180cc, 4 stroke,air-cooled,automatic with reverse |
| Cylinder Arrangement | Single |
| Cooling System | Air Cooled |
| Max Power | 7.5kW/(7000r/min) |
| Max Torque | 11N.m/(6000r/min) |
| Compression Ratio | 10.0:1 |
| Drive System Type | 2WD |
| Start System | Electric |
| Ignition | C.D.I |
| Lubricate | Separated&pressure |
| Air Filter Type | Dry Air-Cleaner Net |
| Transmisson | Chain drive |
| Gear | 3 gears Forward, N, R |
| Battery | 12V/9AH |
| Fuel | 92# Unleaded Gasoline |
| Fuel system | Caburetor |
| Frame /Body/ Suspension / Brakes | |
| Front Suspension | Double Wishbone |
| Rear Suspension | Single Wishbone |
| Front Brakes | Hydraulic Disc |
| Rear Brakes | Hydraulic Disc |
| Parking Brake | Front Hand Packing Brake |
| Front Tires | 10''(23x7-10) |
| Rear Tires | 10''(23x7-10) |
| Wheel Material | Steel |
| Capacities / Dimensions | |
| Net Weight (kg) | 184kg |
| Max Load(kg) | 203kg |
| Wheelbase(mm) | 1200 |
| Ground Clearance(mm) | 160mm |
| Seat Height(mm) | 800mm |
| Fuel Capacity (L) | 6.5L |
| Packing Size(mm) | 1620x1020x750mm |
| Loading Capacity (40'HQ) | 18pcs/20'GP 42PCS/40'HQ |
| Safety / Control | |
| Engine Kill Switch | Yes |
| Speedometer | Optional |
| Hand Brake | Yes |
| Headlights | Yes |
| Tail Lights | Yes |
| Turning Lighe(F/R) | Optional |
| Advantage & Services | |
| 1.CE,ISO certification passed | Before sale:Help customer choose the most suitable equipments. On sales: Inspect the product seriously before out of the factory;organize to delivery according to the contract. After sales:Company can send technical datas for guiding to install the machine. We also can provide 24-hours thlephone or message service. |
| 2.Waranty: 12 month for the machine iteself | |
| 3.ENsure a more accurate measurement | |
| 4.Factory owned, better price and quality | |
| 5.Reasonable and Competitive Price | |
