Sft3208 High Accuracy Fiber Network Testing Handheld RF Optical Power Meter Analyzer

Product Description

Optical Power Meter
Summary SFT3208 handheld optical power meter is a compact and an easy-to-use testing instrument for optical fiber networks, which can be used for absolute optical power measurements as well as for relative loss measurements in optical fibers. It features ingenious appearance, wide range of power measurement, high accuracy and user self-calibration function with high performance-to-price ratio. Features User self calibration function Comfortable LCD display and optional backlight LCD display supports night operation Power measurements in dBm or mw and insertion loss in dB Low battery consumption, more than 240 hours continual operation time for three 1.5V alkaline batteries 10 minutes Auto-off function can be activated or deactivated. ApplicationsMaintenance in Telecom
Maintenance CATV
Fiber Optic Lab Testing
Other Fiber Optic Measurements
Parameter

Type	SFT3208A	SFT3208C
Wavelength(nm)	800~1700nm
Detector	InGaAs
Measurement Range (dBm)	-70~+3	-50~+26
Uncertainty	±5%
Calibrated Wavelength(nm)	850,1300,1310,1490,1550,1625
Resolution(dB)	0.01
Optical Connector	FC(interchangeable SC,ST) / as well as 2.5mm universal
Power Supply	Alkaline Battery(3 AA 1.5V batteries)
Battery Operating Time	240 h with 1.5V Battery(3)
Operating Temperature(ºC)	-10 ~ +60
Storage Temperature(ºC)	-25 ~ +70
Relative Humidity	0 to 95% (non-condensing)
Dimension(mm)	175x82x33
Weight(g)	310

FAQ
1. What are the payment terms that you support?
Usually, we accept T/T, PayPal, Western Union and so on. You can select the termsof payment which is more convenient for you.
2. What about the lead time?
Usually, if there's stock, we ship the goods within 3-5 working days after the deposit is confirmed. lf it is out of stock. the lead time depends.
3.How about the shipping?
When the package is small, we normally choose FedEx, DHL, TNT, and UPS and so on, while the goods have high weight and volume, we suggest using air or sea shipment.
4. How can I place an order?
(1) Negotiation is agreed upon for the product price and specifications.
(2) The Proforma invoice will be sent for confirmation.
(3)After the agreement on the proforma invoice, the customer makes the deposit
(4) Manufacturing will be started as soon as the payment is confirmed by our bank
(5) Ship out the goods within the agreed delivery deadline.
5.Can you do OEM for us?
Yes. If there is a certain order quantity, we can do OEM including printing, logo, and customized model for you.
6.How about the Warranty?
There are 12 months for the warranty. While the warranty is not responsible for those broken by violence or updated with other brands.

---
