Liquid About 10L 15L 20L 25L 30L 50L Pail Chemical Explosion-Proof and Anti-Corrosion Filling Machine for Paint/Perfume/Glue/Glyphosate

Product Description

Model	GZM-30-1PT
Suitable material	Liquid like coating, printing ink, paint, asphalt, glue, lubricant, petrochemical, fineness chemical etc
Weighing form	Filling above level (liquid without foam) Filling under level (liquid with foam)
Filling capacity	5-30KG
Accuracy	0.20%
Filling speed	120-240 containers/hour
Barrel form	Bottle,Jerry Can ,Tin Can,Tin,Pail, Drum,IBC,etc.
Max power	200W
Gas power	0.5MPa
Filling station	1
Work environment	Temperature :-20ºC~45ºCrelative humidity:95%(none dew)
voltage	AC220V /AC380±10% 50Hz
Filling mouth material	SUS304/SUS316/PTFE
Option	Ex-Proof Model Available Upon Request
Products can be customized according to needs, specifications and sizes are mainly based on technical agreements

Product Features1. This filling machine GZM-30 is a semi-automatic device for filling all types of liquids and viscous products. It is the best solution for tins, canisters and pails from 1 to 30 liters. The device stands out for its versatility and does not require installation, so you can start production from the beginning. The interface design is designed for operators and is very easy to use.
2. It is suitable for filling small-mouth barrels within 60kg, and can be filled with both double heads and single heads. The system adopts programmable PLC control, full English guidance, and easy operation; manual barrel loading, automatic filling. Equipped with automatic capping machine.
3. There are two filling methods: bottom filling and top filling:
Bottom filling is suitable for flowable liquids that are easy to foam and generate static electricity. The filling head extends into the bottom of the barrel and lifts up while filling.
Top filling is filling on the liquid surface in the barrel, suitable for filling non-foaming liquids. The filling head is inserted into the barrel mouth and automatically returns if it is not aligned.
4. Real-time display of weighing value.
5. Two speeds for feeding: fast and slow.
6. Two filling modes: net weight/gross weight.
7. Two operation modes: automatic/manual.
8. Three protections: emergency stop/power failure/tank removal.
9. Explosion-proof control box with explosion-proof mark, EXIDIIBT6.
Brand components
Company ProfileShanghai Guangzhi Automation Equipment Co., Ltd. is a production and trading company specializing in the weighing industry. We are located in Shanghai, China's economic city, with convenient transportation and export ports all over the world. We cooperate with state-owned factories and international companies, and the quality is guaranteed.
We mainly focus on providing customers with weighing solutions, from commercial scales to industrial weighing machines. Such as pneumatic valve bag packaging machine, dry mix mortar bag packaging machine, cement packaging machine, natural stone powder packaging machine, flour powder packaging machine, wheat packaging machine, potato starch packaging machine, air packaging machine, granule bag packaging machine, grain packaging machine, fertilizer bag packaging machine, lubricant filling machine, 200 kg drum filling machine, 216L drum filling machine, 208L drum filling machine, ton barrel filling machine, IBC filling machine, jumbo bag packaging machine, ton bag packaging machine, 30L pail filling machine, 50L pail asphalt filling machine, ATEX barrel filling machine, explosion-proof filling machine, etc.
Why choose us1. Packaging solution
we provide professional packaging and logistic service for your option. With plenty of experience and carefully treatment, we make sure the machinery delivery to you is good useful.
2. Pre-sale Service.
pre-sale service will provide by our sales engineers and electrical engineers. offering complete bundle of packaging solutions and professional rationalization proposals and pre-sale testes.
3. After-sale service
we provide free parts and parts delivery, when manufacture defects has been detected during normal operation(vulnerable parts not included)under warranty period(one-year warranty )as well as after-sale service of low cost.
Free training course will be given to your technician at our factory site in Shanghai China.FAQQ1: Are you manufacturer?
A: Yes. We have more than 10 years of manufacturing and exporting experience. We are proud to be the first batch of Chinese manufacturers devoted in large format printers.
Q2: How to buy?
A: Simply contact our sales expert and inform your demands, request for a Proforma Invoice. The order will be shipped after the invoice get paid.
Q3: How can I trust you?
A: Always warmly welcome for visiting our factory. Or have video call. Or arrange any of your friend to come and help you check your goods. Or place order through Trade Assurance Order. Or any other good idea you can feel free to inform. We will do our best to cooperate. We are serious supplier in this industry for long time. You can always rely on us.
Q4: How to send goods to my place?
A: We have regular reliable forwarder agent, can send goods to you by sea, by air, by DHL Express, or if you have agent, we can send to their warehouse in China.
And if you want to combine our products with other items you bought from other supplier, we would also be happy to help.
If you are new for importing, feel free to contact us. We will help check the most suitable transportation method for you.
Q5: How is your warranty?
A: 12 months trouble-free warranty. During warranty period, electric parts are covered with warranty. Users send back defective parts and we send the new one for replacement. Warranty can be up to 3 years if you apply for the warranty extending plan. For more information, please feel free to contact our sales people.
Q6: How is your technical support?
A: We provide 12 months trouble-free warranty and lifetime online support through Whatsapp/ Skype/ Wechat/ Email / Remote Assistant- Teamviewer.
From Monday to Sunday, 9am to 9pm. No need to worry about the technical support due to time difference.
Onsite support also available.

---
