Hand Wheel Controls Die Height Individually Turret Punch Press Tool Grinding Machine

Product Description

Product Features
01. Automatic sharpening(Automatic tool setting, automatic removal).
02. PLC control, automatically complete the grinding process of rough grinding, fine grinding, polishing, etc.
03. Grinding accuracy: flatness±0.01MM.
04. The upper mold of AMADA 85 series AB station only needs to remove the pipe, and then the chuck can be installed for sharpening.
05. Automatic lubrication system.
06. Automatic cooling system(Prevent tool grinding and annealing).
07. Automatic liquid level detection system(Automatically alarm and stop when the coolant is lacking to prevent tool grinding and annealing).
08. Automatic filtration system(Filter cotton can be washed and reused).
09. Safety door protection and alarm function.
10. Grinding overload protection system.
11. Spindle upper limit alarm function.
12. Emergency stop alarm function.
13. Interrupt return function.
14. Exhause system helps trap remaining swarf.

Product Parameters

Grinding Wheel	CBN Ф150
Maximum Grinding Diameter	Ф200
Maximum Grinding Allowance	1mm
Main Spindle Motor	2.2KW, 50Hz
Spindle Speed (RPM)	3000
Maximum Vertical Travel	250mm
Grinding Amount per Pass	0.001-0.02mm
Worktable Motor	0.55KW, 50Hz
Worktable Speed (RPM)	60
Cooling Water Pump	0.12KW, 50Hz
Weight	600kg
Total Power Capacity (KVA)	3.7

FAQ
1.How many models of grinding machine are there?
A: We have 3 models. RG-160;WG-150;IS-160
2.Which brands of molds are suitable for?
A: Suitable for Amada,Murata and Trumph.
3.How can I choose the right fixture?
A: As each brand has different mold sizes, you can contact us.

---
