HDPE Jacket Pipe Extruder Production Line for Making Preinsulated Pipe

US$100,000.00-360,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
HSD
Screw No.
Single-screw
Automation
Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008
Customized
Customized
Condition
New
After-sales Service
All Life
Application
Make Jacket Insulated Pipe
Material
HDPE
Diameter
100-2000mm
Output Capability
1.2t
Worker
2-3 Person
Transport Package
Standard Package
Specification
pipe dia. 1380-2000mm
Trademark
HSD
Origin
Qingdao China
HS Code
8477209000
Production Capacity
50 Units/Year

Product Description

HDPE Jacket Pipe Extruder Production Line for making preinsulated pipe
Product Description

Description of the production: HDPE PU Foam Thermal Pre-insulated thin wall Pipe Extrusion Line. is a high efficiency equipment with high speed and energy saving which is developed by Qingdao Huashida Machinery Co.Ltd., PU foam Pre-insulated Pipe Extrusion line is easy to operate with automatic control system and has long service life.
Prefabricated directly buried insulating pipe cosist of steel pipe, polyurethane foam layer and PE jacket pipe. Because of its special structure, the PU Insulated Pipe is an irreplaceable role in municipal heating engineering.
Detailed Photos

Pipe Application:
PE Pipe produced by this line, is with excellent stiffness, flexibility, high mechanical strength, resistance of environmental stress cracks, resistance to creep deformation, heat-linkage and so on.
It has become the first choice for the city gas pipe, water supply pipe, foundation pipe, landfill collection pipe, watermain, geothermal heating etc.
Compose of Processing Line
1. Automatic Vacuum Feeding
2. Drying Machine
3. Single screw Extruder
4. Mold
5. Calibrating
6. Vacuum calibrating water tank
7. Hauling Machine
8. Cutting Machine
9. Carrier
10. PLC Automatic Control System
Main Specifiction:
Style PE-110/600 PE-365/760 PE-655/1380 PE-960/1680
Main extruder SJ-75/33 SJ-90/33 SJ-120/33 SJ-150/33
Pipe diameter Φ110-600mm Φ 365-Φ 760 mm Φ 655-Φ 1380 mm Φ 960-Φ 1680mm
Capacity 250-300kg/h 400~500 kg/h 850~950 kg/h 900-1100kg/h
Installed power 160kw 420 kw 480 kw 580kw
Length 35m 36 m 40 m 48m
