US$14,500.00-16,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Portable Harvester Type
Backpack Type
Certification
ISO9001:2008, CE
Application Field
Agriculture
Transport Package
Nude Packing
Production Capacity
50000 PCS/Year
Product Description
Feature:
1. Turbo engine power 88hp and Gear Box ZKB85 and HST 45cc are used for higher work efficiency.
2. Fuel tank capacity 130L can meet the whole day's work.
3. All direction grain discharging pipe brings convenience.
4. Grain Tank 0.35m3 can make sure of high unloading efficiency.
5. Rubber Track 500*90*51 and min ground clearance 32cm can make machines work faster in deep mud field.
6. New spring reel is optional.
Parameters as below,
| Model | 4LZ-4.0E |
| Type | Self-propelled full feeding |
Dimension
(Operation) | Length(mm) | 4960 |
| Width(mm) | 2890 |
| Height(mm) | 2700 |
| Weight(kg) | 2800 |
| Engine | Type | In-line, Water cool, Four-stroke, Direct Injection |
| Power(HP) | 88 |
| RPM(r/min) | 2650 |
| Fuel tank(L) | 130 |
| Gear Box Model | Hydraulic Gear Box ZKB85 |
| | HST | 45CC |
| Walking Part | Track(mm) | 500*90*51 |
| Track Gauge(mm) | 1150 |
| Ground Clearance(mm) | 320 |
| Harvesting | Cutting Width(mm) | 2000/2100 |
| Feeding Capacity (kg/s) | 4 |
| Cutting Bar Lift | Hydraulic Control |
| Threshing | Type | Axial Flow Type with Beat Bars |
| Threshing Cylinder (mm) | 620*2000 |
| Cleaning Type | Vibrating Sieves+ Centrifugal Fan |
| Discharging | Small Grain Tank (0.35m3) | Manual |
| Work efficiency | (ha./h) | 0.37-0.66 |
| Crops | | Rice, Wheat, Soybean,Rapeseed |
>>
