Basic Info.
Operating System
Windows 10
Wi-Fi Connectivity
802.11ac
Display Type
Without Screen
Drive Type
256GB SSD Drive
Specification
115*102*41mm
Production Capacity
50000/Month
Packaging & Delivery
Package Size
50.00cm * 45.00cm * 50.00cm
Package Gross Weight
1.000kg
Product Description
Product Parameters
| Product Appearance |
| Type | Spec. | Standard Configuration | Optional |
| Product | Product Type | MINI PC | |
| Special | Standing micro PC | |
| Dimension | 154.3*77.8*77.8mm | |
| Case Material | Plastic | |
| Weight | | |
| System Hardware Configuration |
| Type | Spec. | Standard Configuration | Optional |
| CPU | Model | Meteor lake 125H | Ultra 7 155H |
| manufacturing process | Intel 4 7 nm | |
| core | 14 cores and 18 threads | 18cores and 22 threads |
| cache | 18 MB Intel® Smart Cache | 24 MB Intel® Smart Cache |
| Maximum speed | 4.5 GHz | 4.8 GHz |
| power wastage | 45W / 65W | |
| GPU | Model | Intel® Arc(TM) Graphics | Intel® Arc™ graphics |
| core | 7 | 8 |
| speed | 2.2 GHz | 2.25 GHz |
| resolution | 4096 x 2304 | |
| Memory | Model | 2*SODIMM DDR5 | |
| speed | Up to DDR5 5600 MT/s | |
| Capacity | Up to 96GB | |
| Storage | SSD Capacity | SSD(Up to 2TB) (gen4*4) | |
| SSD Type | M.2 2280 NVME x2 | |
| 2.5 inch HHD | NO | |
| TF card | NO | |
| RTC | BIOS Support | Real-time clock, timed power-up | |
| power-on | BIOS Support | Supports automatic power-on after power-on | |
| diskless network | BIOS Support | Support uefi diskless boot | |
| TPM | CPU Integrated TPM | Supports TPM 2.0 | |
| multi-screen | video output | Support system HDMI*2+type_c*1 three screen display | |
| LED | status indicator | Button light: white | |
| Internet Connection |
| Type | Spec. | Standard Configuration | Optional |
| WIFI | Model | M.2 E_Key | |
| protocols | IEEE 802.11 a, b/g, n, ac,ax (wifi5/6) | |
| Bluetooth | Model | usb | |
| protocols | Support Bluetooth4.2/5.2 | |
| 3G | built-in | NO | |
| 4G | built-in | NO | |
| Ethernet | LAN1 | 10M/100M/1000M/2.5Gbps Adaptive | |
| interface |
| Type | Spec. | Standard Configuration | Optional |
| USB | USB2.0 | NO | |
| USB | USB3.0 | USB3.0 Type-A*4 5Gbps | |
| TF | Expanded External Storage | NO | |
| HDMI | video output | HDMI 2.0 x2 4096 x 2304 @ 60Hz | |
| DP | 4K audio and video output | NA | |
| VGA | video output | NA | |
| RJ45 | Gigabit Ethernet | RJ45 2.5Gbps *1 | |
| Type C | data transmission | Type_C *1 (global function) 10Gbps | |
| POWER | Power Button | x1 | |
| DC IN | Power Supply Input | 5.5/2.1mm DC Jack x1 | |
| Audio-in/out | Audio-in/out | 3.5mm Phone Jack x1 (2-in-1 connector) | |
| Antenna1 | FPC Antenna | WiFi 2.4+5G+BT x1 | |
| Antenna2 | FPC Antenna | WIFI 5.0 | |
| SIM | micro SIM | not support | |
| Software Configuration |
| Type | Spec. | Standard Configuration | Optional |
| OS | Version | Win11/Linux | |
| Environment |
| Type | Spec. | Standard Configuration | Optional |
| Environment | Working Temperature | 0~40ºC | |
| Memory Temperature | -20~60ºC | |
| Humidity | 90% @ 40 °C (no condensation) | |
| Accessory |
| Type | Spec. | Standard Configuration | Optional |
| Power Supply | Desktop/Plug-in | Input 100~240V 50/60Hz Output 19V/6.3A DC Jack 5.5*2.1mm | |
| IR Remote Control | not support | |
| VESA Mount | support | |
