Wide Belt Electromagnetic Segment Pad Sander

Product Description

QCMAC Wide Belt Sander with Electromagnetic Segment Pad (Chinese)-Polishing Machine
Product Description
The whole machine frame uses profile welding with articial aging treatment, making sure machine body to be well maintained. Servo motor lifting assures an accuracy of 0.01mm. Central information processing system, every electromagnet can be independently adjusted and controlled. Uniform sanding pressure Force plus special Angle protection function makes a better suface. The feeding end is equipped with a sensor, which reduces the scanning distance to 16-22mm, so as to control the scanning accuracy more precisely. Electrical Parts
Main motors with thermal relay protection; SIMENS PLC SIMENS Touch screen. Safety Protection
3-color caution light; Emergency stop button on both in-feed and out-feed ends; Belt error/pressure error/ feeding error/ protection. Product Parameters

Woring Width	60-1300mm
Working Thickness	3-110mm
Working Length	≥450mm
Sanding Belt Size	150*4500mm & 1330*2500mm
Feeding Speed	7-20m/min
Main Motor Power	15Kw+15Kw+11Kw
Working Pressure	0.55Mpa
Compressed Air	1.8m³/min
Dust Collection Air Volume	16000m³/h
Dust Collection Air Speed	25m/s

Detailed Photos

---
