Plastic Powder Mixer Machine Mixing Machines PVC Mixer for PVC Extruder with Dosing System

US$8,000.00-30,000.00 1 set (MOQ)

Basic Info.

Model NO.
chiyu mixing system
Type
Pipe Extruder
Plastic Processed
PVC
Product Type
Granulating Extruder
Feeding Mode
Multiple Feed
Assembly Structure
Integral Type Extruder
Screw
Twin-Screw
Engagement System
Full Intermeshing
Screw Channel Structure
Deep Screw
Exhaust
Exhaust
Automation
Automatic
Computerized
Computerized
Wall Material
Stainless Steel SUS304
Wall Thickness
8mm
Model Number
SRL-W500/1000A
Power(W)
67/15kw
Voltage
380V/50Hz/3phase, According to Requirement
Main Electrics
Siemens
Transport Package
Wood Pallet+Stretch Film Package
Specification
5500*4000*4000
Trademark
CHIYU
Origin
Jiangsu Suzhou
Production Capacity
20sets/Month

Product Description

Application:
For all kinds of plastic parts, mixing, drying, coloring and other processes,The unit consists of hot mixer and cooling mixer,is the ideal choice for the production of profiles, pipe manufacturers.
Features:
1.It is the basic equipment of the extruder production line.
2.All important components(Pan,agitator,distribution box,etc.) are manufactured inside the company to ensure the quality of the machines.
3.The mixer lid is double sealed and opened in the pneumatic way.
4.The abrasion resistant coating of the stirring paddle increases the service life,and runs smoothly throungh the static and dynamic balance test.
5.Barrel wall undergoes precise grinder.
6.Thermo control meters adopt RKC from Japan.
Main Technical Parameters:
Item
Model		 Total Volume(L) Effective
Volume(L)		 Production
Capacity
kg/h		 Rotating
Speed(r/min)		 Motor Power
(kw)		 Heat Power/
Cool Medium		 Weight(t)
SRL-W
300/600		 300/600 225/384 550-600 480/964/70 40/55/11 9kw/water 3.5
SRL-W
500/1000		 500/1000 375/660 800-1000 441/886/60 47/67/15 9kw/water 7.8
SRL-W
500/1600		 500/1600 375/1024 800-1000 441/886/51 47/67/18.5 9kw/water 8.5
SRL-W
800/2000		 800/2000 560/1280 1300-1500 330/660/51 110/18.5 self-friction
/water		 10
SRL-W
800/2500		 800/2500 560/1600 1300-1500 330/660/51 110/22 / 11
SRL-W
1000/3500		 1000/3500 750/2240 800-2000 330/660/51 132/37 / 12


Scene Pictures:
Please feel free to contact us if you have any questions.
