Economical and Fully Automatic Three Layers Co-Extrusion Biodegradable Polyethylene Agricultural Film Blowing Machine Made in China

Product Description

Economical and Fully Automatic Three Layers Co-Extrusion Biodegradable Polyethylene Agricultural Film Blowing Machine Made in China
Description :
This film blowing machine set is to satisfy the customer's requirements of high quality, high out put film blowing equipment. It adopts the extruder with force feeding function, precision type ceramic heater, precision type double vents air ring, horizontal type rotary traction system, IBC inner cooling system, fully automatic surface friction type double cut double winders, computer concentrate control system, advanced technique and equipments. Compare with kindred equipment, it has the advantages such as more compact structure, higher output, better produce quality, less energy consume, easier operation. It can be widely used into various kind of high transparence packing film manufacture, and create the considerable economic benefit for you.
Main Parameter:

Type	SJ55-GS1300	SJ60-GS1500	SJ65-GS1800	SJ-GS2300
Max. Lay Flat Width (mm)	1200	1400	1700	2100
Film Layer	3	3	3	3
Film Thickness (mm)	0.02-0.12	0.02-0.12	0.02-0.12	0.02-0.12
Max. Output(kg/h)	200	250	300	400
Raw Material	LLDPE, LDPE, EVA
Screw Diameter(mm)	Φ 45/φ 55/φ 45	Φ 50/φ 60/φ 50	Φ 60/φ 70/φ 60	Φ 75/φ 90/φ 75
Screw L/D Ratio	30.1	30.1	30.1	30.1
Screw Max. Rotation Speed (r/min)	100	100	100	100
Extruding Driving Power(kw)	18.5/30/18.5	22/37/22	30/45/30	55/90/55
Die Structure	IBC Film Tube Inner Cooling System
Air-ring Structure	Double Vents Air Ring
Reversing Haul-off System	Horizontal± 180°
Take-off Wide-up Speed (m/min)	45-120
Total Power(kw)	150	280	280	350
Overall Dimensions(mm)	According to actual machine

Machine Pictures:

---
