| US$119.99 | 10 Pieces (MOQ) |
| GENERAL SPECIFICATIONS | |||
| Nominal diameter | mm (in.) | 461(18) | |
| Nominal impedance | Ω | 8 | |
| Minimum impedance | Ω | 7.9 | |
| Program power (1) | W | 4000 | |
| AES Power rating(2) | W | 2000 | |
| Sensitivity (3) | dB | 97.4 | |
| Frequency range | Hz | 34-1000 | |
| Voice coil diameter | mm (in.) | 125(5) | |
| Chassis material | Aluminium | ||
| Magnet | material | Ferrite | |
| Magnet dimensions (ODxIDxh) | mm | 280x140x25 x2 | |
| Coil material | SV | ||
| Former material | Glass Fiber | ||
| Xmax(4) | mm | 17.5 | |
| Xmech(5) | mm | 26 | |
| Gap height | mm | 14 | |
| Voice coil Wingding height | mm | 42 | |
| SMALL SIGNAL PARAMETERS | |||
| Re | Ohm | 6 | |
| Fs | Hz | 34 | |
| Mms | g | 279 | |
| Cms | mm/N | 0.08 | |
| BL | N/A | 30.1 | |
| Qms | 9 | 7.9 | |
| Qes | 0.39 | 0.37 | |
| Q-factor | Qts | 0.35 | |
| Vas | I | 226 | |
| Le | mH | 2.9 | |
| Sd | cm² | 1325 | |
| Eta 0 | % | 2.9 | |
| SHIPPING INFORMATION | |||
| Net weight | 25.7 | KGS | |
| Multipack size (1) (W x D x H) | 485x485x265 | MM | |
| Multipack weight | 27.7 | KGS | |
