| US$6,000.00 | 1 Piece (MOQ) |
| Main parameters | FL504 |
| Engine Type | QC498T50 |
| Max. Torque (Nm @ engine rpm) | (190~195)@1700 |
| Displacement (L) | 3.168 |
| Fuel tank capacity (L) | 70L/90L |
| Rating power of engine | 36.8/2400 |
| Fuel consumption @ nominal power | ≤248 |
| Air Intake Type | Natually-Aspirated |
| N / Displacement | 4/3.168 |
| No. of gears | 8F+4R/8F+8R/12F+12R |
| Shift method | Sliding sleeve/Synchronizer |
| Max. speed | 34.78km/h |
| Gear position | Command aside |
| PTO Speed | 540/760rpm 540/1000rpm(Optional) |
| The whole machine size (dimensions) mm | 3790×1620×2130(ROPS) 3968×1620×2577(CABIN) |
| Min. operation mass (kg) | 2135(ROPS) 2540(CABIN) |
| Mini turning Radius (m) | 4.3 |
| Rated traction force(KN) | 14 |
| Deck | Flat Deck |
| Wheelbase(mm) | 1991(ROPS) 2041(CABIN) |
| Minimum ground clearance(mm) | 325 |
| Front/rear wheel track | 1250/1300(common) |
| Tyre size | 8.3-20/12.4-28 |
| Steering type | Hydraulic steering |
| Steering Angle (4 x4) | 40° |
