XL6336 Universal Radial Milling Machine

Product Description

Vertical milling machine XL6336 UNIVERSAL RADIAL MILLING MACHINE FEATURES:
1. Taiwan high speed milling head
2. Automatic feeds in X, Y, Z axis
3. Hardened square guide ways
4. Manual lubricate system
5. Spindle speed at 70-7200rpm (V)
6. With capacity both Vertical and Horizontal

MODEL		XL6336
Spindle taper		ISO40(VERTICAL)ISO50(HORIZONTAL)
Spindle travel	mm	140
Sleeve feed	mm/r	0.04/0.08/0.15
Distance from vertical spindle to column	mm	200-600
Distance from vertical spindle to table	mm	180-530
Distance from horizontal spindle to table	mm	0-350
Distance from horizontal spindle to arm	mm	230
Spindle speed range	r/min	63~2917/10(vertical)60~1800/12(horizontal)
Table size	mm	1250x360
Table travel	mm	1000x320x350
Range of longitudinal,cross travel	mm/min	15~370/(MAX.540)
Up/down speed of table	mm	590
T of table(N0./WIDTH/DISTANCE)	mm	3/18/80
Main motor	kw	5.5(vertical)4(horizontal)
Motor of table power feed	kw	0.75
Up/down motor of headstock	kw	1.1
Coolant pump motor	kw	90
Speed of coolant pumps	L/min	25
Overall dimension	mm	2220x1790x2360
N.W./G.W.	kg	2340/2540

---
