| Overall size | |
| Min. Radius of Rear Gyration | 1650mm |
| Min Ground Clearance | 350mm |
| Platform width | 1810mm |
| Engine hood height | 1750mm |
| Platform Height Above Ground | 830mm |
| Transport Length | 5850mm |
| Arm Length | 1600mm |
| Boom Length | 3000mm |
| Bucket Width | 670mm |
| Machine parameters | |
| Machine Weight | 5880Kg |
| Bucket Capacity | 0.28m³ |
| Rated Power | 37KW |
| Cylinders | 4 |
| Hydraulic Pressure | 24MPa |
| Max Grade | 30° |
| Ground Pressuree | 35kpa |
| Max Travel Speed | 2.5-4.5Km/h |
| Max Traction | 38KN |
| Platform rotation speed | 8-10rmp |
| Max Bucket Digging Force | 37.7KN |
| Max Arm Digging Force | 28.4KN |
| Working range | |
| Max. Digging Height | 5760mm |
| Max. Dumping Height | 4030mm |
| Max. Digging Depth | 3820mm |
| Max Digging Radius | 6150mm |
| Min Radius of Rotation | 2100mm |
| Max. Lifting Height of Bulldozer | 350mm |
| Max. Sinking Depth of Bulldozer | 450mm |
| Machine configure | |
| Model No | SD65E |
| Engine Model | Yanmar4TNV494 |
| Pump | Imported MZFB327 |
| Valve | Parker-Korea |
| Spray method | Direct injection |
| Cylinders | 4 |
| Motors | Imported Eaton |
