| Turning-parameters | |
| Max. swing over bed | 320mm |
| Max. swing in gap | 210mm |
| Max.machining length | 915mm |
| Middle carriage travel | 200mm |
| Spindle taper | MT5 |
| Spindle bore | 38mm |
| Max. travel of tail-stock sleeve | 80mm |
| Taper of tail-stock | MT3 |
| Threads metric pitches | 0.5~4mm 15 kinds |
| Threads inch pitches | 9~48T.P.I 23 kinds |
| Transverse feed | 0.10~1.50mm/r |
| Longitudinal feed | 0.025~0.34mm/r |
| Spindle speed range | 60~1600r/mim |
| Motor power | 1500W /50HZ |
| Drilling and milling-parameters | |
| Max.Drilling capacity | 20mm |
| Spindle taper | MT3 |
| Spindle speeds | 200~2200r/mim 4 kinds |
| Motor power | 550W / 50HZ |
| Net weight/gross weight | 475/500kg |
| Overall dimensions | 1620*650*900mm |
| Package Size | 1730*770*1150mm |
