High Performance 95% Total Reflectance PVD Coating Aluminum Sheet

Product Description

SMMT's high performance Al mirror product "L95" is specially designed to perform stable in CoB-LED high temperature and environmental conditions. For achieving higher specular reflectance, the L95 product is applied onto Anodized Al metal strips which provide a low scattering, smooth and hard surface prior to our coating. All layers are PVD coated and applied by the new continuous air-to-air vacuum coating machine from Germany. Our technology gives the possibility to coat our metal strips with high efficiency, high speed and high stability of product properties and quality among the whole length of the metal strip coil. Product & Applications Product Parameters

Product Name	High Performance Mirror	"L95"
Substrate Specification	Material	Aluminum Strip
	Width[mm]	<=1250
	Standard Thickness[mm]	0.3-1.0
	Standard Alloy	1085
	Temper	H18-H19
	Surface	anodized
Mechanical Property	Tensile strength [N/mm2]	>=140
	Yield strength [N/mm2]	>=120
	Elongation A 50%	>=2
	Bending radius for forming	>=1.5 x strip thickness
Optical Property	Total reflectance (Y/D65/2º)[%]	95±2
	Diffuse reflectance (Y/D65/2º)[%]	<5±2
	Iridescence	no visible iridescence
Payment Term	TT, LC
Packing	1. Product surface attached with proctective film 2. plastic film sealed 3. Anti-collision foam 4. Drying agent 5. seaworthy exporting wooden case
Delivery Time	Future goods: 25-35 work days; Ready Stock: 7- 10 days

---
