High Speed CNC Machining Center (VMC1060B VMC1060BL)

Product Description

Vertical Machining Center VMC1060B & VMC1060BL
Table size: 1300x600mm
Table travel(X/Y/Z): VMC1060B --- 1000/600/700mm
VMC1060BL --- 1100/650/700mm
Standard Accessories:
FANUC 0i mate MD CNC system;
Sliding guideway for VMC1060B;
Linear guideway for VMC1060BL;
8000rpm high speed BT40 spindle from Taiwan;
Umbrella type ATC with 16 tools capacity from Taiwan;
Separated electronic handwheel;
Interval auto-lubricating;
Full splash guard;
Ball screw from Taiwan;

Optional Accessories:
The 4th axis / The 5th axis;
FANUC 0i MD, SIEMENS, or other CNC system;
Disc type ATC with 24 tools capacity;
Auto. chip conveyor;

Specification	Unit	VMC1060B	VMC1060BL
Table size	mm	1300x600	1300x600
X-axis travel	mm	1000	1100
Y-axis travel	mm	600	650
Z-axis travel	mm	700	700
Guideway type		Sliding guideway	Linear guideway
Spindle center to column guideway surface	mm	630	630
Spindle nose to worktable	mm	140-840	140-840
T-slot No./width/distance		5/18/100	5/18/100
Spindle taper		BT40	BT40
Max. spindle speed	rpm	8000	8000
Rapid feeding of X, Y axis	mm/min	15000	20000
Rapid feeding of Z axis		12000	18000
Tool magazine capacity		16	16
Magazine type		Umbrella type
Max. diameter of tools	mm	φ80/φ130	φ80/φ130
Max. length of tools	mm	300	300
Main motor power	kw	7.5/11	7.5/11
Max. loading of worktable	kg	800	800
Machine weight	kg	6600	6800
Overall dimension(LxWxH)	mm	3200x2480x2960	3200x2480x2960

Packaging & Shipping
Company Profile

Since the establishment of the Ministry of Foreign Trade, we have participated in various domestic and international exhibitions such as the Autumn Canton Fair, Beijing Exhibition, Shanghai Exhibition, Moscow, Ethiopia, and Russia, and have maintained long-term friendly cooperative relations with exhibition customers.
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
Our Advantages
1. Free replacing parts available in the warranty period. Cost price replacing parts available beyond the warranty period.
2. Quick action and reply for the technical questions at any time in the whole life of the machine.
3. Overseas after service center available in some region.
4. Engineer overseas service available on the requirement of customer(relative cost born by customer).
Customer visited
So far, we have received many customers from abroad, and they are all very satisfied with our company and products
