| Model | DXTT92-FB |
| Max. Working Height | 11.2m |
| Max. Platform Height | 9.2m |
| Loading Capacity | 200kg |
| Max. Horizontal Reach | 3m |
| Up and Over Height | 7.89m |
| Guardrail height | 1.1m |
| Overall Length(A) | 2.53m |
| Overall Width(B) | 1.0m |
| Overall Height(C) | 1.99m |
| Platform Dimension | 0.62m×0.87m×1.1m |
| Ground Clearance(Stowed) | 70mm |
| Ground Clearance(Raised) | 19mm |
| Wheel Base(D) | 1.22m |
| Inner Turning Radius | 0.23m |
| Outer Turning Radius | 1.65m |
| Travel Speed(Stowed) | 4.5km/h |
| Travel Speed(Raised) | 0.5km/h |
| Up/Down Speed | 42/38sec |
| Drive Types | Φ381×127mm |
| Drive Motors | 24VDC/0.9kW |
| Lifting Motor | 24VDC/3kW |
| Battery | 24V/240Ah |
| Charger | 24V/30A |
| Weight | 2950kg |
