| US$0.29-10.00 | 5,000 Meters (MOQ) |
| Brand | PALCONN |
| Specification | 12mm,16mm, 20mm, 25mm, 26mm, 32mm, 40mm, 50mm, 63mm |
| Packing | 100-500m/roll |
| Raw Material | Inside and outside: PEX Middle: Aluminium Two layer glue |
| Standard: | EN ISO21003 |
| Type | Laser & overlapped welding |
| Cross-link Degree | ≥75% |
| Tmax | -40ºC-95ºC |
| Application | Potable water Floor heating Solar energy Radiant heating |
| OEM service | We're factory ,OEM service is welcome |
| Technical details for PEX AL PEX PIPE | |
| Coefficient of thermal conduction | 0.45W/(m.K) |
| Coefficient of thermal conduction for insulation | 0.037W/(m.K) |
| Expansion Coefficient | 2.5x10-5(m.k) |
| Bend Radius | >=5D |
| Working temperature | -40- +95°C |
| Working Pressure | 1.25MPA |
| Oxygen Diffusion | 0mg/1.d |
| Burst Pressure | >=4.0-7 MPA |
| Tensile Resistance | >2100-2650N |
