| US$15,000.00 | 1 Piece (MOQ) |
| Technical Parameters | Model UP-110T | ||
| Injection Unit | A | B | C |
| Screw diameter (mm) | 36 | 38 | 40 |
| Shot Volume (cm3) | 153 | 181 | 201 |
| Injection weight (g) | 138 | 163 | 181 |
| injection pressure (Mpa) | 170 | 144 | 130 |
| Screw speed (rmp) | 220 | ||
| Clamping Unit | |||
| Clamping force (KN) | 1100 | ||
| Open stroke (mm) | 325 | ||
| Max Mold height (mm) | 380 | ||
| Min Mold height (mm) | 135 | ||
| Space between tie bars(mm) | 360x360 | ||
| Ejector force (KN) | 33 | ||
| Ejector stroke (mm) | 90 | ||
| Others | |||
| Pump pressure (Mpa) | 16 | ||
| Motor/driving power (KW) | 11.5 | ||
| Heating power (KW) | 7.5 | ||
| Machine dimension (M) | 3.8x1.2x1.7 | ||
| Machine weight (T) | 3 | ||
| Oiltank cubage (L) | 150 | ||
