| Tech Spec | |
| Product Form | PPC |
| Dimension | 257.2*170*45.95mm |
| Weight | 1.2kg |
| Product Color | Black(Front and Rear Panel: Black,Decorate Board:Black) |
| CPU | RK3568 Quad core 64 bit ARM V8.2 Cortex-A55 up to 2.0 GHz |
| GPU | Mali-G52-2EE |
| Memory | RAM 2GB onboard ROM 16GB |
| Operating System | Android 11 |
| Display | Type: LCD Size: 10.1 inch 16 :10 Resolution: 800×1280 Brightness:450 cd/ |
| Touch Pannel | PCAP |
| WIFI | 802.11b/g/n |
| Bluetooth | BT4.0 |
| I/O Interface | SIM *1 TF *1 |
| Standard USB-A USB3.0*1 + USB3.0*1 OTG | |
| Power interface DC 12V Power connector *1 | |
| ∮3.5mm Standard Earphone Jack *1 | |
| RJ45 *1 (10M/100M/1000M adaptive) | |
| DB9 PORT RS232 *2 | |
| HDMI *1 | |
| MiniPCIE *1 | |
| Power Adaptor | AC100V ~ 240V,50Hz/60Hz output DC 12V/4A |
| Rugged Features | Working temperature: -20 °C to 60 °C |
| Storage temperature: -30 °C to 70 °C | |
| Humidity: 95% Non-Condensing | |
| Certification | IP65 IP65 Report:Water Resistance:IP-X5,Dust Resistance:P-6X a.Inner Nozzle Diameter:6.3mm; b. Water Speed:12.5±0.625L/min; c. Water Pressure:Adjust according to water volumn; d.Central part of water volumn :A round with a diameter of about 40mm at the distance from the nozzle 2.5m. e.Spray time in surface of panele: About 1 min/Square meter;f.Test time:at least 3min; g.Distance between nozzle and panel surface:2.5~3m. After test,there is no water leakage in sample. |
| Accessories | Standard input AC 100V~240V, 50Hz/60Hz output DC 12V/4A adapter |
| Standard PPC_ Hook assembly, material: galvanized sheet, specification: 17.8 * 16.2 * 10mm, thickness: T=1.5mm (including cross screw * 1, specification: PM5 * 30, nut φ 8 * 3 Quantity: 4 | |
| Standard antenna 2.4-2.5/5.15-5.85GHZ 2dBi (SMA), size: 51.5mm, nut diameter: 7.8mm | |
