Machines for Lattice Tower Manufacturing, APM1616 FINCM Tower Power Transmission Line CNC Hydraulic Automatic L-Bar Punching Line Machine 160X160X16mm

Product Description

Product Description
APM1616 FINCM Tower Power Transmission Line CNC Hydraulic Automatic L-Bar Punching Line Machine 160X160X16mm
It is mainly used for customers to manufacture angle steel components, complete typing, punching, fixed length cutting on angle steel. Simple operation, high production efficiency.

Technical specification of APM1616:

Model	APM1616
Processing Angle Steel Range (mm)	40*40*4-160*160*16(Q345B)
Nominal Typing Force	1030KN
Punching Nominal Force	950KN
Nominal Cutting Force	3000KN
Maximum Punching Diameter	φ25.5mm
Quasi-distance Positioning Stroke	20-140mm
Angle Steel Feed Speed	40(m/min)
Maximum Blank Length	12m
Number of Print Header Groups	4
Number of Prefixes in Each Group	18
Header Size	14x10x19mm
Cut off Method	Single Edge Cutting
Cooling Method	Air-cooled
Total Power of Equipment	42KW
Net Weight (t)	15t

Angle feeding Speed: 40m/min, the effiency is about 1000 holes/hour
The finished angle conveyor is rotated to one side by pneumatic power. The max. Length of finished angle is 8 m.
There are four transverse conveyors which can infeed automatically.
Type of programming: Keyboard input, USB interface input, floppy disc input.
Working environment:
Working temperature: 0~ 40 degree
Power: Three phase four wire system
AC Voltage: 380V
Fluctuation of voltage: ± 10%
Frequency: 50 Hz
Main outsourcing components list of APM1616:

No.	Name	Brand	Manufacture
1	AC Servo Motor	Panasonic	Japan
2	PLC	Mitsubishi	Japan
3	Input Module	Mitsubishi	Japan
4	Output Module	Mitsubishi	Japan
5	Positioning Module	Mitsubishi	Japan
6	Towline	Igus	Germany
7	Electromagnetic unloading valve	ATOS	Italy
8	Relief valve	ATOS	Italy
9	Electro-hydraulic directional valve	JUSTMARK	Taiwan
10	Manifold	AirTAC	Taiwan
11	Air valve	AirTAC	Taiwan
12	cylinder	CKD	Japan
13	Duplex	CKD	Japan

Relateed Products
Company Profile
Shandong FIN C N C MACHINE CO., LTD is located in Jinan high tech Development Zone, is committed to the development, research, design, manufacture, sales of CNC machine tools, such as processing angle bar, beam channel profiles, steel plates, tubesheet and flanges. It is mainly used in iron tower, steel structure, heat exchanger, boiler, bridge, truck and other industries.FIN CNC machines exported to 50+ countries across globe market. Our company has strong R & D center with 30 engineers team, they have 20 years of experience ; 280 staff, plant area about 270,000 sqm. Main products: CNC Angle Line, CNC Beam Drilling Sawing Machine, CNC Plate Drilling Machine, CNC Rail Processing Machine, CNC Tubesheet Flange Drilling Machine, Truck beam plate punching machine. The company drafted many China national standards for C N C angle line
Cooperatine Supplier

Product Process Control
Sales Network
Our Service
FAQ
1. When can you arrange shipment?
For machines available in stock, the shipment can be arranged within 15 days after getting advance payment or L/C;
For machines non available in stock, the shipment can be arranged with 60 days after getting advance payment or L/C.
2. What can you do if my machines have problems?
1) We can send you free components if machines are in warranty period;
2) 24 hours service on line;
3) We can assign our engineers to serve you if you want.
3. Do you provide machine operation training?
Yes. We can send professional engineers to the working site for machine's installation, commissioning and operation training.
4. Which machine model shall I choose when I purchase from you?
Please share us your material size and your processing request, then we will recommend our machine most suitable and most cost effective for your work demand.
5. What's your machine's market share in China?
Our market share in China is about 70%+, and we've exported to 50+ countries across the globe market, since year 1998.

---
