Injection Blow Machine for Plastic Industry

US$15,000.00-18,000.00 1 set (MOQ)

Basic Info.

Model NO.
UP-140
Type
Tube Head Injection
Structure
Horizontal
Plastic Type
Thermoplastic
Plasticizing Way
Screw Type
Clamping Way
Hydraulic
Automation
Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008
Heating Power
16kw
Machine Weight
6.3t
Tank Volume
350L
System Pressure
16MPa
Transport Package
Film Packing
Specification
5.8*1.55*2.15
Trademark
UP
Origin
China
HS Code
8474809090
Production Capacity
500sets Per Year

Product Description


Ningbo Union Power Machinery Co., Ltd. - China Servo Injection Molding Machine
Product Description
A. Modulus of Capacitance: The injection molding machine guide pillar (Green column) features precise positioning, size, and maximum allowable modulus of capacitance, along with a minimum closure thickness.
B. Nozzle Parameters: The machine includes a spherical nozzle with specified diameter, aperture, outer diameter, maximum extension length, and positioning aperture for accurate molding.
C. Code Mold Parameters: The mold is designed with code mold holes and slots of specific sizes for efficient production.
D. Ejection Mechanism: The ejection point's position, ejector rod diameter, and optional ejection force and stroke are provided for smooth mold ejection.
E. Mold Opening Stroke and Maximum Opening Distance: The machine offers precise control over mold opening stroke and maximum opening distance for varied molding requirements.
Technical Parameters Model UP-140T
Injection Unit A B C
Screw diameter (mm) 38 42 45
Shot Volume (cm3) 215 260 302
Injection weight (g) 194 237 272
injection pressure (Mpa) 186 152 132
Screw speed (rmp) 215
Clamping Unit
Clamping force (KN) 1400
Open stroke (mm) 380
Max Mold height (mm) 450
Min Mold height (mm) 135
Space between tie bars(mm) 420*420
Ejector force (KN) 46
Ejector stroke (mm) 120
Others
Pump pressure (Mpa) 16
Motor/driving power (KW) 13(14)
Heating power (KW) 8.2
Machine dimension (M) 4.2*1.2*1.9
Machine weight (T) 3.4
Oiltank cubage (L) 190
