High Sensitivity Geophone 4.5Hz for S Wave and Shear Wave

US$1.00-200.00 1 Piece (MOQ)

Basic Info.

Model NO.
Horizontal Geophone
Vertical Lines
1
Geophone Direcction
Horizontal for S Wave
Geophone
Range From 1Hz to 100Hz
Connector
Kck, Kcl, Lck, Kooter, MP16, 408, Split Plate, Mueller
Spike
75mm Steel Soil Spike or Tripod Snowbase
Cable
4.6mm to 5.3mm, 3 Cores
Case
Waterproof Reinforced Land Case
After-sales Service
Available
Warranty
3 Years
Transport Package
Standard Export Carton
Specification
1x1, 3x1, 3x2, 6x1, 6x2
Trademark
SEIS TECH
Origin
China
HS Code
9015800090
Production Capacity
50, 000sets/Year

Packaging & Delivery

Package Size
20.00cm * 15.00cm * 10.00cm
Package Gross Weight
0.300kg

Product Description


Type ST-4.5B(Equivalent to SM-6/H-B 4.5Hz)
Natural frequency ( Hz ) 4.5±0.5
Open Circuit Damping 0.65±10%
Coil resistance (ohms) 3500±5%
Open circuit sensitivity (V/m/s) 80±5%
Harmonic distortion ( % ) <=0.3
Moving Mass ( g ) 11.3
Max. coil excursion p-p (mm) 4
Max. tilt angle 5º
Element Diameter (mm) 25.4
Element Height (mm) 36
Element Weight (g) 86
Operating Temperature( ºC ) -40ºC to + 100ºC
Warranty Period 3 years
All parameters specified herein are rated at a temperature 20ºC±2ºC. 3- year limited warranty on basic element exclusive of high voltage, lightening or physical abuse.
Type ST-4.5A
Natural frequency ( Hz ) 4.5±0.5
Frequency Response Range(Hz) 5Hz to 1000Hz
Open Circuit Damping 0.7±10%
Coil resistance (ohms) 4100±5%
Open circuit sensitivity (V/m/s) 100±5%
Harmonic distortion ( % ) <=0.6
Moving Mass ( g ) 11.3
Max. coil excursion p-p (mm) 4
Max. tilt angle 5º
Element Diameter (mm) 25.4
Element Height (mm) 36
Element Weight (g) 86
Operating Temperature( ºC ) -40ºC to + 100ºC
Warranty Period 3 years
All parameters specified herein are rated at a temperature 20ºC±2ºC. 3- year limited warranty on basic element exclusive of high voltage, lightening or physical abuse.
