Automatic Hard Wood 4FT Plywood Veneer Peeling Machine
1. Fearures
Spindleless veneer peeling machine is used for make veneer .
And it is suitable for the eucalyptus, pine, cotton wood and another log.
The quality of the veneer determines the quality of the plywood, so controlling the quality of the veneer is the premise and the most important part of producing standard plywood.
veneer peeling machine is a very technical equipment in plywood line equipment.
2. Technical Parameters
Working length970mm - 1270mm
Working diameter range80~500mm
Max. working speed60m/min
Veneer thickness0.6~5mm
Double rollers motor power11kw
Single roller motor power5.5kw x 2sets
Screw Feeding motor power7.5kw
Rotary clipper motor power2.2kw
Rubber belt conveyor motor2.2kw
Machine size4700x1900x1500mm
Machine weight5000kgs
Reducer ModelR87 Hard helical
RemarkIncluding 6 meter veneer conveyor

Product Show
COMPLETE PLYWOOD PRODUCTION MACHINE LINE
