High Speed Carving Milling Center

Product Description

High Speed Carving Milling Center
I.Product Features
1.KR-1640 adopts vertical machining center bed type marriage, integral casting. The machine head moves up and down through slide rails on the herringbone column, and the worktable part adopts a cross slide table structure to realize the XY coordinate movement on the plane. The overall rigidity is stronger and the stability is better.
2.The three-axis guide adopts imported rolling linear guide, which has low dynamic and static friction, high sensitivity, high positioning accuracy, excellent servo drive performance, and improves the accuracy and precision stability of the machine tool.
3.The spindle system of the machine tool uses high-speed electric spindles with a maximum speed of 18,000 rpm. The bearings use NSK P-class spindle bearings. After the complete set of spindles are assembled under constant temperature conditions, they have passed dynamic balance correction and running-in tests to improve the entire set of spindles. Service life and reliability.
II.Technical Parameter

Item	Item	Specification	Unit
Stroke	X axis (left and right stroke)	500	mm
	X axis (back and forth stroke)	500	mm
	Z axis(Up and down stroke)	450	mm
	Distance from spindle center to column guide rail	600	mm
	Distance from spindle end surface to worktable surface	150-550	mm
Workbench	Workbench size	2000*500	mm
	T-slot(number*size*distance)	3*18*140	mm
Spindle	Spindle taper (model no./installation size)	ER25/32
	Spindle center distance	230	mm
	Spindle speed	18000	rpm
Motor	Spindle motor	5.5*8pcs	KW
	X axis motor	3	KW
	Y axis motor	3	KW
	Z axis motor	3	KW
Feed rate	Max cutting feed rate of 3 axis	12	m/min
	Three-axis rapid movement	30	m/min
Accurancy	Positioning accurancy	±0.005/300	mm
	Repeatability	±0.005/300	mm
Specification	Weight	800	kg
	Dimension(L*W*H)	3350*2600*2600	mm
	Air pressure requirement	6-9	kg/cm²
	Rated power	55	KW

III.Production workshop
IV.Package and Loading
V.Certificate:
Quanzhou Yueli Automation Equipment Co.,Ltd was founded in 2013,which covers an area of 3000 square meters. The company is located at the China Plumb Town--Nanan, Fujian. It is a production enterprise lead by drilling tapping compound machine, drilling tapping centers and drilling tapping milling process center. The company is committed to serving various of industries such as sanitary ware, fire protection valves, hardware, electrical hardware, aerospace, machine manufacturing and so on.
If you have any interest, pls feel free to contact at any time.

---
