| US$2.00-10.00 | 1 Piece (MOQ) |
| Model | 4V110-M5 | 4V120-M5 | 4V130C-M5 | 4V130E-M5 | 4V130P-M5 | 4V110-06 | 4V120-06 | 4V130C-06 | 4V130E-06 | 4V130P-06 |
| 4A110-M5 | 4A120-M5 | 4A130C-M5 | 4A130E-M5 | 4A130P-M5 | 4A110-06 | 4A120-06 | 4A130C-06 | 4A130E-06 | 4A130P-06 | |
| Position and Way NO. | Two-position Five-way | Three-position Five-way | Two-position Five-way | Three-position Five-way | ||||||
| Effective Sectional Area | 10mm²(CV=0.56) | 7mm²(CV=0.40) | 12mm²(CV=0.67) | 9mm²(CV=0.5) | ||||||
| Model | 3V110-M5 | 3V120-M5 | 3A110-M5 | 3A120-M5 | 3V110-06 | 3V120-06 | 3A110-06 | 3A120-06 |
| Position and Way NO. | Two-position Three-way | Two-position Three-way | ||||||
| Effective Sectional Area | 10mm²(CV=0.56) | 12mm²(CV=0.67) | ||||||
| Port Size | Air inlet=Air Outlet=Exhaust=M5×0.8" | Air inlet=Air Outlet=Exhaust=G1/8 | ||||||
| Working Medium | Air (40Micron Filtered) | |||||||
| Acting Type | Inner Guide Type | |||||||
| Working Pressure | 0.15~0.8MPa | |||||||
| Max.Pressure Resisance | 1.2MPa | |||||||
| Working Temperature | 5~50°C | |||||||
| Voltage Range | ±10% | |||||||
| Power Consumption | AC:2.8VA DC:2.8W | |||||||
| Insulation&Protection Class | F Class.IP 65 | |||||||
| Wiring Form | Lead wire or Connector type | |||||||
| Max.Frequency | 5 Cycle/Secretary | |||||||
| ShortestActivate Time | 0.05 Second | |||||||
