High Efficiency Vacuum Meat Tumbling Machine

Product Description

High efficiency vacuum meat tumbling machine

GR series horizontal tumbling machine is a series of products with capacity of 8-1000kg. Users can choose the corresponding machines according to the output.
Vacuum tumbling machine by using the principle of physical impact, let the meat turning up and down inside the cylinder, each hit, beat, to massage, pickled.
It has the following advantages:
(1) Increase meat adhesive force and elasticity
(2) Reduce the meat broken rate
(3) Enhance production rate and water retention
(4) Tenderize meat and make the structure stability
(5) Well taste and good apparence
(6)Made of high quality stainless steel, compact structure, low noise, smooth operation.

Model	Power	Rotating speed	Vacuum degree	Utility voltage	Overall dimensions (mm)	Effective volume
GR-15L	1.3KW	7r/min	≤-0.8mp	380v	880X450X700	8L/barrel
GR-20L	1.3KW	7r/min	≤-0.8mp	380v	910X500X800	10L/barrel
GR-30L	1.3KW	7r/min	≤-0.8mp	380v	910X550X850	15L/barrel
GR-50L	1.5KW	7r/min	≤-0.8mp	380v	910X730X850	25L/barrel
GR-70L	1.85KW	7r/min	≤-0.8mp	380v	1200X660X1000	35L/barrel
GR-100L	1.85KW	7r/min	≤-0.8mp	380v	1130X712X1100	50L/barrel
GR-200L	2.25KW	7r/min	≤-0.8mp	380v	1600X1100X1450	100L/barrel
GR-300L	2.25KW	7r/min	≤-0.8mp	380v	1760X1000X1500	150L/barrel
GR-600L	2.95KW	7r/min	≤-0.8mp	380v	2000X1000X1550	350L/barrel
GR-800L	4.75KW	7r/min	≤-0.8mp	380v	2250X1200X1700	400L/barrel
GR-1000L	6.6KW	7r/min	≤-0.8mp	380v	2560X1350X1770	500L/barrel
GR-1200L	6.6KW	7r/min	≤-0.8mp	380v	2560X1400X1870	600L/barrel
GR-1600L	8.6KW	7r/min	≤-0.8mp	380v	2530X1500X1950	800L/barrel
GR-2000L	8.6KW	7r/min	≤-0.8mp	380v	2880X1700X2150	1000L/barrel

Working steps:
1.Set rolling and kneading total time;
2.Set intermittent time;
3.Rolling,kneading and vacuum at the same time ;
4.Forward rolling and kneading the materials,reverse discharge the finished ;
5.Continuous rolling and kneading;
6.Intermittent rolling and kneading;
7.Enhance the binding of the meat,enhance the flexibility of the product ;
8.Improve products of the section, prevent broken when slicing produce.
Control panel:
Tumbler use:
Tumbler can make meat evenly pickle, can improve the meat's binding force and product elasticity; can improve the product's taste and cross-section effect; can enhance water retention, increase product yield; can improve the product's internal structure, energy saving and high efficiency. The whole machine is made of stainless steel and has a compact structure. Both ends of the drum adopt a spin-on-seal cap structure, which maximizes the space in the drum to beat, making the effect of the tumbling products even, low noise, reliable performance, easy operation and more efficient use. high.
Tumbler benefits:
The first is to make the product tumbling under vacuum, which will make the physical volume of the product large and soft. Make the finished product taste better.
Second, tumbling the product under vacuum will reduce heat generation when the product rubs and beats. And the product will not oxidize under vacuum conditions. Therefore, the product will not deteriorate during the kneading process.
Third, physical bulking of the product under vacuum conditions is beneficial to the absorption of excipients.
Packing
Machines are wrapped in plastic bags first before being convolved with straw rope.
Then the machines are put in strong wooden case, lined with metal wire if necessary.
Our Services

1	We provide 1 year guarantee with life-time service.
2	We provide English manual and video for operation
3	If required, we could send technicians for installation and commissioning, training.
4	Any problem in operation or others about the Soybean oil processing plant, you can contact with us we will give solution in 24-48 hours. If big problem, we can send technician to customer's local place.

Contact information:
If you have interest in this Produce food grade cooking oil Soybean oil processing equipment, kindly please contact:
Mobile/: +86 17630364947

---
