| SPECIFICATIONS |
| RANGE OF OPERATION | Boom length | 5700mm |
| Arm length | 2900mm |
| Maximum digging radius | 9873mm |
| Minimum turning radius | 3560mm |
| Maximum digging depth | 6592mm |
| Maximum vertical mining depth | 3929mm |
| Maximum digging height | 9616mm |
| Maximum unloding height | 6830mm |
| The radius of the end of gyration platform | 2794mm |
| DIMENSION | (Length*width*height) travel position | 9600*2990*3000mm |
| Wheel base | 3635mm |
| Track Gauge | 2400mm |
| Width Of Crawler | 600mm |
| Total width of the car | 2990mm |
| Total length of walking mechanism | 4440mm |
| The total width of belt off | 2980mm |
| Ground clearance of counterweight | 1096mm |
| Min ground clearance | 475mm |
| TECHNICAL PARAMETERS | Angle of rotation | 360° |
| Machine weight | 22300kg |
| Engine model | Is |
| Rated Power | 128.5KW |
| Rotary speed | 10.7min |
| Walking speed(high/low) | 5.9-3.2km/h |
| Ground specific pressure | 43.5kpa |
| Climbing ability(%) | 70% |
| Digging force | 77.4KN(standard)/81.3KN(turbocharged) |
| Volume Of Bucket | 1.2m3 |
| Main pump | Kawasaki(Japan) |
| Control valve | Parker |
| Travel motor and swing motor | Doosan(korea) |
We are a leading manufacturer and exporter of wheel excavators, crawler excavators, sugarcane harvesters, sugarcane grab loaders, multi-function excavators. We have nearly 20 years of professional experience, and our products have been exported to many countries.
