Crane Machinery Use Power Flexible Cable Rubber Welding Cable Silicone Rubber Cable

Product Description

Crane Machinery Use Power Flexible Cable Rubber Welding Cable Silicone Rubber Cable
Standard :IEC60245 / VED 0282
Construction : 1.Conductor: Annealed flexible copper conductor (class5) or Tinned Copper conductor(Class5) for Flat Rubber 2.Insulation:EPR Rubber(Ethylence-propylene) 3.Insulation Color: 2core :Blue/Brown(Flat Rubber)
3core :Blue/Brown/Yellow&Green
4core :Blue/Brown/Yellow&Green/Grey
5core :Blue/Brown/Yellow&Green/Grey/Black 4.Sheath:EPR Rubber(Ethylene-Propylene
CR Rubber(Poly-chloroprene) for Flat Rubber 5.Sheath Color:Customized
Characteristic:
1.Temperature Rating: -30ºC up to 70ºC
2.Voltage Rating:300/500V
3.Testing Voltage:2000V
4.Min inner bending radius: 7x overall diameter
4x overall diameter for Flat Rubber
5.Behaviour in fire: Flame retardant to IEC60332-1
Application:
Light rubber cable H05RR-F is used for easy-duty and medium mechanical loads in dry areas.Suitable for household,kitchens,offices and workshops for smaller electrical devices(washing,vacuum-cleaners,irons,household appliances,soldering sets) and mobile devices operating in heavier conditions,such as light industrial and agricultural machines. Not suitable for permanent outdoor use. Ozone-resistant,allowed contact with oils.greases. Flat rubber cable H05RNH2-F is used for decorative lighting. Suitable for in dry,damp or wet areas,indoor & outdoor, as the insulated conductor for lighting fixtures on squares,in garden.
Technical Parameters:

No.of cores x Nominal section area	Nominal Construction of conductor	Nominal Insulation thickness	Nominal Sheath thickness	Nominal Overall diameter	Nominal Cable weight	Max.Resistance of conductor at 20ºC
No.X mm²	No.X mm	mm	mm	mm	kg/km	<=(Ω/km)
H05RR-F Round Light Rubber Cable 300/500V
2x0.75	24X0.20	0,6	0.8	6.1	53	26.7
2x1.0	32X0.20	0,6	0.9	6.6	64	20
2x1.5	30X0.25	0,8	1	7.8	95	13.7
2x2.5	50X0.25	0,9	1.1	9.2	140	8.21
2x4.0	56X0.30	1,0	1,2	10.8	180	4.95
3x0.75	24X0.20	0,6	0.8	6.6	65	26.7
3x1.0	32X0.20	0,6	0.9	7.0	77	20
3x1.5	30X0.25	0,8	1	8.4	115	13.7
3x2.5	50X0.25	0,9	1.1	9.9	170	8.21
3x4.0	56X0.30	1,0	1.2	11.7	240	4.95
4x0.75	24X0.20	0,6	0.8	7.3	80	26.7
4x1.0	32X0.20	0,6	0.9	7.6	95	20
4x1.5	30X0.25	0,8	1.0	9.4	145	13.7
4x2.5	50X0.25	0,9	1.1	11.1	210	8.21
4x4.0	56X0.30	1,0	1.2	13	300	4.95
5x0.75	24X0.20	0,6	0.8	8.1	100	26.7
5x1.0	32X0.20	0,6	0.9	8.4	115	20
5x1.5	30X0.25	0,8	1.0	10.3	170	13.7
5x2.5	50X0.25	0,9	1.1	12.4	255	8.21
5x4.0	56X0.30	1,0	1.2	14.5	355	4.95
H05RNH2-F Flat Rubber Cable 300/500V
2x0.75	30X0.25	0.8	1	5.0x13.0	122	13.7
2x1.0	50X0.25	0.8	1.1	5.7x13.3	147	8.21
