| Functional principle | double-acting |
| Cushioning | pneumatically |
| adjustable | |
| Magnetic piston | with magnetic piston |
| Piston diameter | 200 mm |
| Piston rod thread | M36x2 |
| Standardization | CNOMO / NFE 49-001 |
| Stroke | 100 mm |
| Sealing material | Polyurethane |
| Compressed air connection | G 3/4 |
| Compressed air connection type | Internal thread |
| Temperature resistance | Optionally heat-resistant |
| Standards | CNOMO / NFE 49-001 |
| Compressed air connection | Internal thread |
| Working pressure min./max. | 2 … 10 bar |
| Ambient temperature min./max. | -20 … 80 °C |
| Medium temperature min./max. | -20 … 80 °C |
| Medium | Compressed air |
| Max. particle size | 50 µm |
| Oil content of compressed air | 0 … 5 mg/m³ |
| Pressure for determining piston forces | 6.3 bar |
