Kebei 12kw Integrated Flat and Profile Laser Cutting Machine for Versatile Applications

Product Description

Company Profile
Wuhan kebei international trading Co., Ltd. was established in 2006, with a production base located in the Gedian Economic and Technological Development Zone in the eastern part of Optics Valley. It covers an area of 60 acres, has a standardized factory building of 31000 square meters, and has nearly 400 employees, including nearly 70 research and development personnel. KEBEI is a high-tech company that integrates the research and development, production, and sales of laser equipment. The company is engaged in the development, production, and sales of intelligent laser processing equipment, including efficient laser processing products such as profile steel laser secondary processing lines, laser cutting machines, laser pipe cutting machines, and laser texturing machines. It is the source manufacturer of full process intelligent laser equipment.
Product Description
The steel fabrication field is still using the traditional manual and semi-automatic material handling methods, and there is an urgent need for an efficient and high quality processing method to improve efficiency and quality, and reduce labor costs. We are committed to providing high efficiency, high precision, and high cost performance automatic processing equipment to solve these problems by providing high precision cutting and significantly reducing

Product Parameters

serial number	name	Technical Parameters
1	Steel cutting range	Height B ≤ 500mm Width H ≤ 1200mm Length L≤ 26000mm (customized on demand)
2	Laser power	12kw/20kw/30kw
3	X-axis travel	26000mm
4	Y-axis travel	1750mm
5	Z axis travel	910mm
6	A-axis stroke (rotary axis)	±90°
7	C-axis stroke (rotary axis)	±90°
8	U axis travel (height adjustment axis)	0- 50mm
9	X/Y/Z maximum positioning speed	30m/min
10	X/Y/Z positioning accuracy	≤ 0.1 mm
11	Cutting accuracy	≤ 0.5 mm

Sample display



Packaging & Shipping
Our production are transported by sea. we package and load it in the container then ship to foreignal country.


Certifications

Exhibition Pics

FAQ
Q: If my machine is broken. Can you repair it for me?
A: Yes. We have free training online. If there is big trouble with your machine in the warranty time, we can repair it.
Q: What factors should be considered when choosing a laser cutting machine?
A: When choosing a laser cutter, consider factors such as the type of material being cut, required accuracy, speed, production cost and machine energy efficiency.
Q: Is the laser cutting machine safe to use?
A: Laser cutters are generally safe to use when proper safety procedures are followed, they can also cause hazards such as burns, eye injuries, and exposure to fumes. Using proper safety equipment and training is crucial.Our production are examined by a series of tests , we can ensure the quality of using.

---
