Cast Iron High Pressure Dryer Cylinder

US$3,999.00-69,999.00 1 Piece (MOQ)

Basic Info.

Model NO.
Dia 1500
Certification
ISO 9001:2000, ISO 9001:2008, CE, ASME
Surface Treatment
Polishing
Manufacturing Process
Casting
Material
Cast Iron
Working Pressure
up Tp 1.3MPa
Face Length
up to 11meters
Standard
ASME/Ad2000/Eac
Material Type
Caet Iron / Steel Plate
Transport Package
Export Wooden Package.
Specification
Dia 1500
Trademark
GAOXIN
Origin
Dandong, China
HS Code
84399900
Production Capacity
1500 Pieces/ Year

Product Description

The diameter and face length can manufacture as the client's requirment
The Main Technical Parameters Used In Paper Machinery
diameter(mm)
 design pressure Mpa Material Hardness HB face length(mm) shell thickness(mm) roughness(um) working speed(m/min)
∅1500 0.3-1.3 HT300 180-260 1000-11000 20-45 ≤0.4 200-1500
∅1800 0.3-1.3 HT300 180-260 1000-11000 23-50 ≤0.4 200-1500
∅2000 0.3-1.3 HT300 180-260 1000-11000 24-55 ≤0.4 200-1500
∅2500 0.3-1.3 HT300 180-260 1350-11000 30-47 ≤0.4 200-1500
∅3000 0.3-1.3 HT300 180-260 1350-11000 32-56 ≤0.4 200-1500
∅3660 0.3-1.3 HT300 180-260 1450-11000 36-65 ≤0.4 200-1500
>∅3680 0.3-1.3 HT300 180-260 1450-11000 38-67 ≤0.4 200-1500
<∅1500 0.3-1.3 HT300 180-260 1000-11000 18-27 ≤0.4 200-1500
