CNC Cutting Machine with Circular Saw Blade Cutting Tool Hydraulic CNC Automatic Saw Machine

US$52,100.00-60,550.00 1 Set (MOQ)

Basic Info.

Model NO.
HD-160X Circular saw machine
Application
Metal
Process Usage
Metal-Cutting CNC Machine Tools
Movement Method
Linear Control
Control Method
Semi-Closed Loop Control
Numerical Control
CNC
Performance Classification
High-End CNC Machine Tools
Certification
ISO9001:2015, ISO14001:2015
Condition
New
MOQ
1 Set
Model No
X Series Circular Saw Machine
Feed System
AC Servo Motor + Ball Screw
Voltage
380VAC
Circular Saw Blade Specifications
460X50xt2.7/T2.25
Automatic Feed Loader
6 Meters
Cutting Applications
Copper,Alloy Steel,Stainless Steel,Mild Steel
Features
High Speed,High Precision Cutting,Durable Quality
Shipment Way
Shipment by Vessel / Railway
Delivery Time
About 20-30days
Transport Package
Standard / Wooden Box Packaging
Specification
L 7750 * W 2200 * H 1900mm
Trademark
HENGERDA
Origin
Fujian, China
HS Code
8461500090
Production Capacity
300sets/Mothly

Product Description

Product Description
About CNC Automatic High-Speed Circular Saw Machine:1. Man-Machine Interface System
The easy-to-operate intelligent automated servo system with user-friendly touch screen and PLC control system ensures the efficiency and reliability of program operation.2. One-Piece Machine Foundation
The machine foundation uses high strength casting ensures stable machine performance, high cutting efficiency,and precision. Foundation is equipped with a circulating water cooling tank, which can satisfy the needs of using water-based coolant fluid when cutting tough alloy steel materials.3. New Gearbox Structure
The innovative designed gearbox structure and configuration apply to a wide range of cutting materials.4. Remnant Management Device (Third vise)
The unique short remnant clamping structure(P series)changed from a single cylinder to double cylinder separate actions with a vertical clamping device, increase the devise stability and reliability, blade lifetime, yield rate, and saves costs.5. Innovative Automatic Feeding Device
The material feed utilizes a servo-controlled motor with ball screw and linear guiding. Specially designed structure of feed clamp yaw effectively increases the precision and reliability.6. Spray-Mist Lubricant Cooling System
The advanced MQL circular saw blade spray-mist lubricant technology can increase blade service life.

Standard

Optional
1 One set of two-axis electrical system 1 Oil mist collector
2 Hydraulic system 2 Extended feed loader
3 Automatic spray-mist lubrication system 3 Power-driven wire brush
4 Automatic material feed loader 4 Cooling water pump
5 Spiral type chip conveyor 5 Automatic chain type chip conveyor
6 Wire brush 6 Third Vise
7 One air spray gun 7 Extended carrying device for cut-off workpiece
8 Circular saw blade
9 One set of tool kits

Product Parameters
X SERIES HD-160X CIRCULAR SAW MACHINE TECHNICAL DATA
Specifications HD-160X 2-Axis
CUTTING
CAPACITY
Round bar (mm) 40-160
Square bar (mm) 40-110
Trimming length (mm) 10-100
Single feed length (mm) 10-800
Remnant length (mm) 80
Perpendicularity tolerance (mm) ±0.05/100
SAW BLADE Dimensions (mm) Φ460 x Φ50 x T2.7 / t2.25
Pin hole (mm) Φ90/4/Φ14
Number of teeth (Z) 40, 54, 60, 72, 80, 100, 120
PARAMETERS Working voltage (V) 380
Total power (KW) 31.5
Machine weight estimated (loader included) (KG) 6000
Machine dimensions estimated (mm) L 2500 x W 2200 x H 1900
Machine dimensions estimated (loader included) (mm) L 7750 x W 2200 x H 1900
LOADER Number of pieces (P) Φ160 x 6 m x 6
Length (m) 3-6 m
* Please note: all product technical information, parameters, specifications, dimensions, and designs shown in this catalog are subject to change without prior notice. For more information, please contact Hengerda.
