2BV5110 Steel Liquid Ring / Water Ring Vacuum Pump for Paper Making Chemical Industry

Product Description

Product Description
The 2BV series water ring vacuum pumps and compressor is mainly used for sucking gases and water vapor,Particularly suitable for pumping pollution-free gas and steam (special gas needs to be specified when ordering), and the suction pressure can reach 33mbar absolute pressure (97% vacuum degree). When the water ring vacuum pump works for a long time when the suction pressure is close to the limit vacuum (saturated vapor pressure of working fluid), it is necessary to connect with the cavitation resistant pipe in order to get rid of the screaming and protect the pump.
In conjunction with Shandong University, China University of petroleum and other units, our company has continuously optimized its products and launched 2BV series water ring vacuum pumps. With its excellent performance and many advantages, our company has become a new generation of energy-saving products and will comprehensively replace SK, 2SK series water ring vacuum pumps and W, WY, WL and other reciprocating vacuum pumps with the same energy.
Our Advantages
1.The direct connection design of the motor saves space, is easy to install and maintain.
2.All adopt mechanical seal as standard configuration.
3.It is equipped with a cavitation protection pipe interface. If it works for a long time under the limit pressure, it will automatically open the cavitation protection pipe interface, which can maximize the suction effect and eliminate the cavitation sound, and effectively protect the vacuum pump.
4.The whole series is equipped with stainless steel impeller, which improves the corrosion resistance of the vacuum pump.
5.The unique flexible exhaust port design will not produce over compression, ensuring the best efficiency of the vacuum pump within its performance range.
Typical Use
------Oil and gas recovery. ------Biological medicine ------Food Processing ------ Single crystal furnace
------Vacuum forming ------Vacuum flame refining ------Electronic photovoltaic. ------Semiconductor synthesis
Product Parameters
Basic parameters

Type	Maximum air volume m3/min	Pressure limit Pa	power kW	revolution rpm	Motor explosion-proof grad	Water consumption L/min	Noise dB(A)	weight kg
2BV2060-EX	0.45	3300	1.1	2880	d II BT4	2	62	39
2BV2061-EX	0.87	3300	1.5	2880	d II BT4	2	65	45
2BV2070-EX	1.33	3300	2.2	2880	d II BT4	2.5	66	66
2BV2071-EX	1.83	3300	3	2880	d II BT4	4.2	72	77
2BV5110	2.75	3300	4	1450	(Ordinary motor)	7	63	153
2BV6110 (Ex)	2.75	3300	4	1450	d II BT4	7	63	153
2BV5111	3.83	3300	5.5	1450	(Ordinary motor)	8.5	68	208
2BV6111 (Ex)	3.83	3300	5.5	1450	d II BT4	8.5	68	208
2BV5121	4.68	3300	7.5	1450	(Ordinary motor)	10	69	240
2BV6121 (Ex)	4.68	3300	7.5	1450	d II BT4	10	69	240
2BV5131	6.68	3300	11	1450	(Ordinary motor)	15	73	320
2BV6131 (Ex)	6.68	3300	11	1450	d II BT4	15	73	320
2BV5161	8.3	3300	15	970	(Ordinary motor)	20	74	446
2BV6161 (Ex)	8.3	3300	15	970	d II BT4	20	74	446

Detailed Photos
Water ring pump(304 stainless steel) High efficiency roots + water ring vacuum pump unit
High efficiency roots + water ring vacuum pump unit
Vacuum pump is used in the field of chemical plant
General Manager Speech
Deeply cultivate the vacuum technology, and research,develop and manufacture the vacuum equipment to provide the best solution in the vacuum field and make the vacuum application easier.
Company Profile
Shandong Kaien Vacuum Technology Co., Ltd. is a high-tech enterprise integrating R & D, production and operation of vacuum equipment. The company has strong technical force, excellent equipment and considerate after-sales service. The product manufacturing process is managed in strict accordance with IS09001 quality system. It mainly produces and sells screw vacuum pump, roots pump, claw vacuum pump, runoff vacuum pump, scroll pump, water ring vacuum pump, vacuum unit and other vacuum systems.
New plant planning
The company's products have been for a number of food, medicine, refrigeration, drying plants and a number of transformer related equipment manufacturers for vacuum equipment. The products are widely used in vacuum drying and dehydration, kerosene vapor phase drying, vacuum impregnation, vacuum metallurgy, vacuum coating, vacuum evaporation, vacuum concentration, oil and gas recovery, etc.
High precision machining equipment
The company cooperates with many scientific research institutions and universities, such as Shandong University, China University of petroleum, Shandong Institute of mechanical design, etc.with colleges and universities to research and develop core technologies, and owns dozens of independent intellectual property patents.Our technology is leading, the product quality is stable, the product has a good reputation in China's domestic market, is sold all over the country, and is exported to Europe, America, Africa, the Middle East and Southeast Asia,We adhering to the basic tenet of quality, reputation and service, the company takes leading-edge technology of vacuum pump as its own responsibility, and wholeheartedly serves customers of vacuum equipment application in various industries with rigorous working attitude and professional working style.
Product quality wins consumer cooperationIn shipment ISO 9001 High tech enterprise certificate
Welcome to send your needs, we will provide you with the best service,
provide the greatest help!!!

---
