1. Specification
| WEIGHTS AND DIMENSIONS | length: | 2970mm |
| Width: | 1360mm |
| Height: | 2105mm |
| Wheel Base | 1710mm |
| Dry Weight: | 570kg |
| Laden Weight: | 1340kg |
| SOUND LEVEL(DBA) | At ear level : | 65dba |
| At3ft(0.914m): | 60dba |
| At30ft(0.914m): | 50dba |
| DRIVE SYSTEM | Motor: | AC motor |
| Controller: | Seperately excited,400 amp max., |
| Anti-roll away braking and alarm |
| Antistall motor protection.Regenerative braking . |
| Diagnostic indicator.Full torque,reduced speed reverse. | |
| Electrical System: | 48volt 8*6V Trojan t-105 batteries |
|
| FRAME | MIG welded uni-body,high strength steel |
|
| TRRES &BRAKES | | |
| Front wheel: | Two 12X7 vaccum tire |
| Rear wheel: | Two 12X7 vaccum tire |
| BRAKES Type: | Front-Disc/Rear-Drum/Mechanical parking brake |
| | |
| SPEED/ENDURANCE MILEAGE | Forward Speed: | 0-40kph |
| Reverse Speed: | 0-15kph |
| Endurance mileage: | 100km |
| CHARGER | Typeo of Charger: | Ferroresonant transformer.Ferroresonant |
| Input Voltage | 240VAC+/-10%input,50HZ |
| Estimated Full Reacharge Time: | 6hours,-8hours |
| OTHER FEATURES | Other Standared Features: | Battery diacharge indicator, |
| reverse warining indicator, |
| Operator presence seitch ,hour meter headlight switch, | |
| two cup holders ,glove box |
