Sdlg E6210f 21t Medium Size Crawler Excavator with Imported Engine

US$98,270.00-114,480.00 1 Piece (MOQ)

Basic Info.

Model NO.
s d l g
Transmission
Hydraulic Transmission
Drive Type
Internal Combustion Drive
Bucket Capacity
1.0~1.5m³
Size
Medium-Sized
Certification
ISO9001: 2000
Condition
New
Overall Operating Weight
24400kg
Max. Digging Radius
10260mm
Max. Digging Depth
6980mm
Max. Digging Height
9690mm
Engine Brand
Volvo
Engine Type
Inter-Cooled, Four-Cylinder
Engine Power
138kw
Emission Standard
Tier III
Min. Fuel-Consume Ratio
206g/Kw.H
Hydraulic Control Type
Pilot Proportional Control Valve
Hydraulic System Type
Constant Power Negtive Flow Control
Transport Package
RO-RO, Container
Specification
2890*3190*3040mm
Trademark
SDLG
Origin
Linyi, Shandong, China
Production Capacity
50000unit/Year

Product Description


SDLG E6250F 25t medium size hydraulic excavator for mining
E6250F is a core product that is developed by SDLG after fully researching the Chinese market. It features a high-strength chassis, heavy-duty working units, and an optimized matching hydraulic system and is suitable for tough conditions.
Overall dimension
Overall width of upper assembly 2890mm
Overall width 3190mm
Overall height 3040mm
Tail swing radius 2940mm
Overall height of engine hood 2370mm
Ground clearance of counterweight 470mm
Wheelbase 3850mm
Crawler length 4650mm
Crawler gauge 2590mm
Crawler pad width 600mm
Min. ground clearance 470mm
Overall length 10205mm
Overall height of boom 3430mm
Overall parameters
Bucket capacity 1.2m³
Overall operating weight 24400kg
Max. excavation force 176KN
Slew speed 11.3r/min
Traveling speed (low/high) 3.3/5.5km/h
Average ground pressure 48.5kPa
Max. digging radius 10260mm
Max. digging depth 6980mm
Max. digging height 9690mm
Max. dumping height 6800mm
Min. front slewing radius 3890mm
Engine
Model SD70B
Type Four-stroke,inter-cooled, supercharged
Rated Power@Revolution Speed 138kW
Displacement 7146mL
Cylinder bore × stroke 108*130mm
Emission standard GB20891-2014 China Phase III
Rated fuel consumption 206g/kw.h
Max. torque 870N.m
Traveling/swing system
Qty. of carrier rollers (single side) 2
Qty. of track rollers (single side) 9
Traveling brake type Wet disc brake
Swing mode Hydraulic drive internal tooth
single-row ball-bearing
Swing brake type Wet disc brake
Hydraulic system
Hydraulic control type Pilot proportional control valve
Hydraulic system type Dual pump constant power negative flow control system
Max. flow 2*240+18L/min
Operating pressure 330kgf/cm2
Fill capacity
Fuel 380L
Engine oil 32L
Hydraulic oil 330L
