US$29,500.00-32,000.00
|
1 set
(MOQ)
|
Basic Info.
Application
Construction, Stone Industry
Cutting Ability
High Speed
Blades Combination Way
Tower-Type
X-Axis Stroke
4500-7000mm
Y-Axis Stroke
2600-4000mm
Specification
8500*5500*3850mm
Production Capacity
1000set/Year
Product Description
Product Description
The Multi-blade Stone Block Cutting Machine FY-1650, equipped with multiple blades, is suitable for cutting granite, basalt, marble, and quartz blocks into slabs. It demonstrates excellent performance in cold regions such as Russia. This classic and practical bridge saw is capable of cutting blocks into both thin and thick slabs. It features a Siemens PLC control system and Hiwin linear guide with oil bath. Additionally, it can accommodate up to 30 thin saw blades for efficient operation.
Product Parameters
| Model No. | FY-1650 | FY-2250 | FY-2850 |
| Main Frame Specification | Crossbeam Type | / | DL-QS800 | DL-QS800 | DL-QS800 |
| Crossbeam Height | mm | 800 | 800 | 800 |
| Crossbeam Length | mm | 7000 | 7000 | 8500 |
| Crossbeam Width | mm | 700 | 700 | 700 |
| Sidebeam Length | mm | 5000 | 5000 | 5000 |
| Spindle Diameter | mm | 120 | 120 | 120 |
| Middle Frame Height | mm | 2550 | 2550 | 2550 |
| Motor Power specification | Spindle Rotation | kw | 75 | 75 or 90 | 75 or 90 |
| Lift Cylinder | kw | 4 | 4 | 4 |
| Left and Right Travel | kw | 5.5 | 5.5 | 5.5 |
| Front and Back Travel | kw | 2.6*2 | 2.6*2 | 2.6*2 |
| Gross Power | kw | 90 | 90 or 105 | 90 or 105 |
| Whole Machine Datas | Gross weight | T | 19.7 | 19.7 | 19.7 |
| Dimension (L x W x H) | mm | 8500*5500*3850 | 8500*5500*3850 | 10000*5500*3850 |
| For more details datas, pls feel free to contact us. Looking forward to get your inquiry! |
Detailed Photos
Main Features 1) The Siemens smart PLC control system ensures high levels of automation performance and ease of use.
2) The machine's structure is made steady and the lifting stable through the adoption of four pillars for spindle sliding.
3) A two-slider frame structure, driven synchronized by a screw, provides high stiffness and stability.
4) The sliding system of the X and Y axes on linear guides and racks, both lubricated in an oil bath, guarantees smooth operation and high production. Machine Parts
Siemens smart PLC control system
Machine Parts
Name: 6 big strong pilllars
Use: sliding guide for spindle
Covered by fabric for preventing pollution.
Linear Guide
Brand: Hiwin
Original: Taiwan, China
Famous products, top quality use on crossbeam and carling for good performance.
Machine Parts
Name: Circle Blade Original: China Up to 32 pieces of blade can be hanged for efficient production of thin slabs.
