Walking Tractor with 7HP 8HP 10HP 12HP 15HP Diesel Engine for Export

Product Description

1) good for dry field working
2) it can drive many implements, such as rotary tiller, rice and wheat harvester, trailer,plough, pump,corn seeder, peanuts seeder, etc.
3) more than 30 years technology and design, quality is good.

Mode	SX-8	SX-10	SX-12	SX-15	SX-18	SX-20
Power	8HP	10HP	12HP	15HP	18HP	20HP
Structure weight(kg)	270	290	300	480	480	480
Overall dimensions (L*W*H)	2120x 840 x 1160			2220x 1250 x 1220
Wheel track( mm)	680-740
Engine Type	Single cylinder,horizontal,4 stroke
Tire size	6.00-12( w-tire)			6.00-16( w-tire)
Gearbox style	main transmission and vice- transmission , 6 forward gears, 2 reverse gear full power shift. (3 + 1)×2 composition formula circular gear wheel column.
Clutch style	riple-plate,single-action,standard,dry-friction,long engaging friction
Min Ground Distance
Transmission	two belt			three belt
Rated Speed(r/min)	2200
Drivetrain final drive	single-stage spur gear circle column wheel drive
The fuel tank volume (L)	11			13
Engine lubricating oil (L)	1.5-2			2.5-3.2
Gearbox lubricants (L)	3-3.3			3-3.3
The cooling water injection amount (L)	12-13			13.5-15
Basic	Basic

Q1.Are you factory or trading company?
A: We are factory, our factory located in weifang city.
Q2.How about the working life of your walking tractor?
A: Accordingly to the feedbacks from our customers, our walking tractor can be used for about 3 to 5 years. The quality of our tiller is very good, so do not worry.
Q3.How many years warranty your company provide?
A: We provide our customers one year warranty, during warranty period, if there is any parts of the machine went wrong, we will send free ones to you immediately and will guide you how to fix it.
Q4.If the wearing part break down, what to do?
A: We normally send many pieces wearing part together with your order.
Q5. Is it difficult to install the machine?
A: The main parts of the machine will be installed by our enginner, customers only need to install the wheel and accessories like rotary blade.?
Q6.How to use this machine?
A: We will send video and operating manual to you and train you how to use and maintain the machine.
Q7.What is your MOQ?
A: One set is available is you are final user or want to test the machine as an sample. For distuributer, normally our MOQ is 20ft container, but one set is also availble for you to test the machine quality. We offer you different price according to your order quality.
