Walking Tractor with 7HP 8HP 10HP 12HP 15HP Diesel Engine for Export

Negotiable 100 Sets (MOQ)

Basic Info.

Model NO.
7hp-15hp
Farming Policy
Dry Cultivating Machinery
Power Source
Diesel
Operation
Arable Machinery, Continuous Running Operation
Traction Type
Traction
Drive Type
Belt
Arbor Configuration
Horizontal Axis
Certification
ISO
Color
Customized
Transport Package
Plywood Case
Specification
7hp-12hp
Trademark
wolong
Origin
Weifang
HS Code
8701100000
Production Capacity
120, 000 Units Per Year

Product Description


1) good for dry field working
2) it can drive many implements, such as rotary tiller, rice and wheat harvester, trailer,plough, pump,corn seeder, peanuts seeder, etc.
3) more than 30 years technology and design, quality is good.
Mode SX-8 SX-10 SX-12 SX-15 SX-18 SX-20
Power 8HP 10HP 12HP 15HP 18HP 20HP
Structure weight(kg) 270 290 300 480 480 480
Overall dimensions
(L*W*H)
2120x 840 x 1160 2220x 1250 x 1220
Wheel track( mm) 680-740
Engine Type Single cylinder,horizontal,4 stroke
Tire size 6.00-12( w-tire) 6.00-16( w-tire)
Gearbox style main transmission and vice- transmission , 6 forward gears, 2 reverse gear full power shift.
(3 + 1)×2 composition formula circular gear wheel column.
Clutch style riple-plate,single-action,standard,dry-friction,long engaging friction
Min Ground Distance
Transmission two belt three belt
Rated Speed(r/min) 2200
Drivetrain final drive single-stage spur gear circle column wheel drive
The fuel tank volume
(L)
11 13
Engine lubricating oil
(L)
1.5-2 2.5-3.2
Gearbox lubricants
(L)
3-3.3 3-3.3
The cooling water injection amount
(L)
12-13 13.5-15
Basic Basic

Q1.Are you factory or trading company?
A: We are factory, our factory located in weifang city.
Q2.How about the working life of your walking tractor?
A: Accordingly to the feedbacks from our customers, our walking tractor can be used for about 3 to 5 years. The quality of our tiller is very good, so do not worry.
Q3.How many years warranty your company provide?
A: We provide our customers one year warranty, during warranty period, if there is any parts of the machine went wrong, we will send free ones to you immediately and will guide you how to fix it.
Q4.If the wearing part break down, what to do?
A: We normally send many pieces wearing part together with your order.
Q5. Is it difficult to install the machine?
A: The main parts of the machine will be installed by our enginner, customers only need to install the wheel and accessories like rotary blade.?
Q6.How to use this machine?
A: We will send video and operating manual to you and train you how to use and maintain the machine.
Q7.What is your MOQ?
A: One set is available is you are final user or want to test the machine as an sample. For distuributer, normally our MOQ is 20ft container, but one set is also availble for you to test the machine quality. We offer you different price according to your order quality.
