High Frequency Vibration Shaker Table for Concrete Moulds

US$500.00-1,600.00 1 Piece (MOQ)

Basic Info.

Model NO.
ZDP-800
Type
Concrete Vibrator
Shotcrete Type
Semi-Dry
Machining Process
Welded Molding Machine
Structure
Rotor Type
Productivity
120m²/h
Feeding Height
Over 500mm
Vibrating Amplitude
2.0mm
Certification
ISO9001: 2000, CE
Condition
New
Color
Blue
Commodity
High Frequency Vibration Shaker Table
Voltage
110-550V
Power
1kw*2
Noise
50dB
Frequency
50 or 60Hz
Surface Treatment
Painting
Material
Carbon Steel
Motor Phase
3
Special Design
Accept
Transport Package
Standard Export Plywood Case
Specification
Carbon steel
Trademark
YongQing
Origin
Henan, China
HS Code
8474809090
Production Capacity
100 Sets/Month

Product Description

high frequency vibration shaker table for concrete moulds
Parameters of Vibration Table
Model
 Table Size(m2)
 Power(kw)
 Amplitude(mm)
 Loading Weight(kg)
ZDP-500
 0.25
 0.25*2
 2-5
 300
ZDP-600
 0.36
 0.37*2
 2-5
 500
ZDP-800
 0.64
 0.75*2
 2-5
 800
ZDP-1000
 1.0
 1.1*2
 2-5
 1000
ZDP-1200
 1.44
 1.5*2
 2-5
 1200
ZDP-1500
 2.25
 1.1*4
 2-5
 2000
ZDP-2000
 4.0
 1.5*4
 2-5
 2500
ZDP-3000
 9
 1.5*6
 2-5
 3000

Remarks: Support to customize based on customer's requirement.
