US$2,650.00
|
1 Piece
(MOQ)
|
Basic Info.
Key Word 2
304 Stainless Steel Pulverizer Machine
Crushing Degree
Fine Grinding Machine
Crushing Style
Grinding and Impact
Principle
Cylinder Culling
Cutter Material
High-Speed Steel
Finished Surface
Gear Process
Compressive Strength (For Crushing)
>300MPA
Tongs′ Features
Adjustable Tongs
Transport Package
Export Wooden Cases
Production Capacity
30-1500kg\H
Product Description
Stainless steel multifunctional coffee grain bean spice Pulverizer machine
1. Working Method
(1) The machine uses the relative movement between the active fluted disc and the fixed fluted disc to impact, grind and crush the target materials.
(2) The size of granules can be achieved by changing of the screen.
2. Introduction
(1) The machine has the fea-tures of easy structure. Solid, stable running and good efficiency.
(2) The crushed ma-terial is discharged directly from the grinding chamber of the main frame.
(3) In addi-tion, the whole machine is, made of stainless steel, with smooth inside walls to and avoid powder accumulation on the inside walls.
(4) The machine are in accordance with national require-ment, achieving "GMP" standard.
3. Applications:
This grinder machine can be mainly used for grinding various grains, dry spices and herbs, herbal medicines containing roots and branches, chemical materials, and some other hard and brittle materials.
Such as: grains,roasted coffee bean,spices,herbs,salt,sugar,pepper,walnut shells,seed,etc.After grinding, fine powder can be made.
| Model | WSBX-20 | WSBX-30 | WSBX-40 | WSBX-60 |
| Capacity(kg/h) | 30-150 | 50-300 | 80-800 | 120-1500 |
| Speed of principal axis(r/min) | 4500 | 3800 | 3400 | 2600 |
| Size of input granules(mm) | < 6 | < 10 | < 12 | < 15 |
| Fineness of products (mesh) | 12-120 | 12-120 | 12-120 | 12-120 |
| Power(kw) | 4 | 5.5 | 7.5 | 15 |
| Weight(kg) | 250 | 320 | 450 | 600 |
| Overall size (L× W× H) (mm) | 550× 600 × 1250 | 600× 750 × 1450 | 750× 900 × 1550 | 950× 1000 × 1850 |
>>
