Features:
1,All plates are made of imported steel, high hardness, high density and high brightness.
2,Can be etched with high-definition pattern, long using life.
3,Various kinds, full range that covering plates of single side and both sides
4. Strong anti-rust
5 Flatness high, scraping clean
Technical parameters:
Style
| hight Quality oil steel
| Imported oil steel
| Chromium steel
|
Material Composition
| GCr15
| 9CrWMn
| 9Cr12MoV
|
Surface heat treatment hardness
|
HRC63±1
|
HRC63±1
|
HRC62±1
|
Board flatness
| Ink cup:500:0.05mm
Ink tray:500:0.005mm
| Ink cup:500:0.05mm
Ink tray:500:0.005mm
| Ink tray:500:0.05mm
Ink tray:500:0.005mm
|
Board surface finish
| matt:Ra0.1μm
glossy:Ra0.01μm
mirror: Ra0.005μm
| matt:Ra0.1μm
glossy:Ra0.01μm
mirror:Ra0.005μm
| matt:Ra0.1μm
glossy:Ra0.01μm
mirror: Ra0.005μm
|
Rust force
| First class
| Second class
| Fifth class
|
Scratch Views
| 150,000 impressions
| 300,000 impressions
| 1000,000 impressions
|
Plate thickness range of processing
|
10.2-10.5mm
|
10-15mm
|
10mm
|
Applications
| Abs pet pvc pe,etc ink
| Abs pet pvc pe,etc ink
| Pp Highly corrosive ink
|
|
| |
|
