Single Trunnion Assemblies for ADSS Cable

Product Description

Product Description
Trunnion Assemblies-Single Cables
Full range of ADSS cable coverage Installation with through bolt or banding Can be used as a stringing block (with inserts removed), not exceed 30 structures 3/8" Bolt torque 13.5N.m,do not over-torque Max line angle installed(horizontal):22°(11° per side) Max sag angle installed(vertical):22°(11° per side) Not be used in systems with line voltages greater than 69KV Features & Benifits May be used as a pull-through by removing the bushing inserts Double cable supports option High-strength aluminum Smaller and more compact design Facilitates faster installation Color-coded range taking inserts for easy identification Versatile mounting styles to fit different structure types: bolted, banded or standoff Banding and pole hardware supplied by customer Lowers the total cost of installation Span Length: 600 ft.-NESC Heavy 1,200 ft.-NESC Light

CABLE O.D. RANGE		ESTIMATED WEIGHT		BUSHING COLOR CODE
INCHES	MILLIMETERS	LBS	KG
0.325" - 0.375"	8.26 - 9.53	2.06	0.934	Green + White
0.376" - 0.419"	9.55 - 10.64	2.06	0.934	Orange + White
0.420" - 0.474"	10.67 - 12.05	2.05	0.93	Purple + White
0.475" - 0.525"	12.07 - 13.34	2.05	0.93	Blue
0.526" - 0.575"	13.36 - 14.61	2.05	0.93	Orange
0.576" - 0.625"	14.63 - 15.88	2.04	0.925	Brown
0.626" - 0.675"	15.90 - 17.15	2.04	0.925	Green
0.676" - 0.725"	17.17 - 18.42	2.03	0.921	White
0.726" - 0.775"	18.44 - 19.69	2.03	0.921	Red
0.776" - 0.825"	19.71 - 20.96	2.02	0.916	Purple
0.826" - 0.875"	20.98 - 22.23	2.02	0.916	Yellow
0.876" - 0.925"	22.25 - 23.50	2.02	0.916	Pink
0.926" - 0.959"	23.52 - 24.36	2.02	0.916	Blue + White
0.960" - 1.045"	24.38 - 26.54	2.02	0.916	Gray

Product Test
Company Information
Certificate
Packaging & Shipping

Trade terms	FOB, EXW, CIF, DDU, DDP
Payment terms	T/T, L/C, Negotiable
MOQ	100
Supply capability	100000 pieces per month
Lead time	usually 10 working days
Shipment	Express, air, sea
Port	Shanghai, Ningbo, Shenzhen
Sample availability	Yes
Sample time	usually 3-5 days
Packaging	Normal: Plastic bag & Carton & Pallet Special: Customized packing

---
