Double Heads Saw Cutting Saw Machine for Aluminum Window Door Making Machine

Product Description

Product Description
1). Used for cutting wide aluminum alloy profile and curtain wall profile , but also corner connector cutting;
can process two stations.
2). Pneumatic rotation and angle rotation at vertical 45° and 90°.
3). Pneumatic rotation and angle rotation at horizontal 45° and 90°.
4). Can manually set arbitrary angle within 45°~90°; horizontally; pneumatic rotation;
5). Single saw blade can operate independently;.
6). Manual measuring; equipped with measuring locking fine tuning appliance(optional digital display);
7). Saw hood can open and close safety protection independently;
8). Machine head connects with profile conveyor.
Product Parameters

Brand Name	Mag
Power supply	380V 50Hz
Input power	2*2.2KW
Air pressure	0.6-0.8 M pa
Main motor rotation speed:	2800rpm.
Max/min Cutting length	480-4500mm
Saw blade dimension:	φ450× φ30*4.4
Cutting angle:	90 ° ~45 °
Cutting W X H	240*135 ( mm )
Repeat locating length	≤0.2mm
Angle cutting tolerance	±5′
Plane of cutting surface	≤0.10
Cutting profile surface roughness	Ra12.5um
Size: (width X high X long)	5750*1300*1500MM
Weight:	1800Kg
